How to connect Tesla Wall Connector (Gen3) EV charger with Reduxi controller
Connect your Tesla Wall Connector (Gen 3) to the Reduxi Controller.
Text description of this image
Product photo of a wall-mounted white EV charger on a white background. Housing is glossy white with a curved shape and the word 'TESLA' printed in spaced letters near the top. A black charging cable with a black handle is plugged into the housing on the right side and a black cable hangs down from the lower part of the housing, fading out at the bottom.
1 Technical documentation
Manufacturer documents for the Tesla Wall Connector (Gen 3):
- Installing a Wall Connector – Tesla installer page: commissioning, Wi‑Fi connection, registration and firmware updates.
- Wall Connector 3 Install Manual (Type 2, EMEA, en-GB) – Installation manual with specifications, commissioning and power sharing.
- Power Management – Static, dynamic and group power management.
2 Required equipment
- Tesla Wall Connector (Gen 3), installed and commissioned
- Wi‑Fi network at 2.4 GHz with WPA2 security for the Wall Connector
- Reduxi Controller in the same network
- Laptop or tablet with internet access to configure the device in Reduxi
3 Install and commission the Wall Connector
3.1 Installation and commissioning
Find the instructions to connect and configure the Wall Connector on the manufacturer page: Installing a Wall Connector.
3.2 Wi‑Fi connection
- The Wall Connector supports 2.4 GHz networks (802.11 b/g/n) with WPA2 security.
- Each unit has its own Wi‑Fi network name and password. They are printed on a label at the rear of the unit and on the cover of the Quick Start Guide.
- A Wi‑Fi connection is not required for power management. Tesla recommends it for firmware updates and remote troubleshooting.
3.3 Power management
The Gen 3 Wall Connector has three power management features:
- Static: the installer selects a fixed power level during installation.
- Dynamic: the charge rate follows the load of the house. It needs a Tesla-approved power meter, sold separately, and works with a single Wall Connector.
- Group: up to six Gen 3 Wall Connectors share power.
4 Log in to the Reduxi web interface
You can open the Reduxi web interface in two ways:
Text description of this image
Screenshot of three Reduxi mobile app screens side by side, with cyan boxes and number badges 2 to 4. Left screen (dashboard, dark theme): menu icon at top left marked with a box and badge 2; 'reduxi' logo; tabs 'Real time data' (active) and 'Statistics'; price 5.79 € and temperature 3.2 °C; energy flow diagram with a house in the centre (-1.25 kW) and icons with values 69.0 W, 1.3 kW, 1.1 kW (red ring), -165.0 W with 97 % (red ring) and 0.0 W values at the bottom; tabs 'Power' and 'Energy'; bottom navigation: Dashboard, Diagnostics, Device control, Settings. Middle screen (side menu): 'reduxi' logo, 'Number of locations: 1233', heading 'Reduxi device management', entries '+ Add Reduxi location' and 'Reduxi devices' (marked with a box and badge 3), then 'My profile' and 'About app'. Right screen (device page): Back; picture of a black Reduxi controller with two Ethernet ports; status 'Connected'; card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'; card 'Connect to configurator': 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' with button 'Activate tunnel connection' (marked with a box and badge 4); card 'Unit details' with field 'Unit ID'.
Text description of this image
Screenshot made of two parts side by side. Left part: Reduxi mobile app screen on a dark background. Top: Back button; picture of a black Reduxi controller with two Ethernet ports and a terminal block; status 'Connected' with a Wi-Fi icon. Card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'. Card 'Connect to configurator' with a key icon: 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' and button 'Open configurator', marked with a cyan box and number badge 5. Below: card 'Unit details' with a field 'Unit ID' (value not visible). Right part: Reduxi Configurator opened in a browser, marked with a cyan frame and number badge 6. Header: back arrow, 'Tunnel connection', reload icon. Left sidebar with icons (lightning, chip, lightning bolt, bar chart, gear). Page 'Home' with a green link icon. Green notice: 'New patch available. Click here to apply.' with a close X. Time 09:12:56. Energy flow diagram with a house in the centre (1.700 kW) and icons for grid (0.000 kW), solar (1.700 kW), battery (green, 0.000 kW and 0.800 kW), a device at left (0.900 kW), electric vehicle and a charger or device at bottom. Label 'Energy manager' at the bottom.
http://reduxi.local. You can find the controller's IP address in your router's device list or in the Reduxi app under Reduxi devices.admin · Password: admin (factory default)Text description of this image
Screenshot of the Reduxi Configurator login page in a Chrome browser window. The address bar shows 'Not secure' and 'reduxi.local'; the address bar is marked with a cyan box and an enlarged copy of it (cyan box, text 'Not secure reduxi.local') is shown at the left, connected by a cyan line. Page background: light grey line drawing of a house with solar panels (green), a wall box, an inverter, a car and a charger. Top left: 'reduxi configurator' logo. Login box in the centre with title 'Login', a language selector (English flag, 'English'), a username field and a password field, and a dark 'Login' button.
Text description of this image
Screenshot of the Reduxi Configurator web interface after login, light theme. Top left: 'reduxi configurator' logo. Header bar: 'Home' at left, green 'Connected' status at top right. Left sidebar: expanded section 'Devices' with a list of entries, then collapsed sections 'Manager' and 'Configuration' and 'Settings'. Main area: energy flow diagram. House in the centre with ring, value 24.20 kW. Grid icon at top left, 24.20 kW (red dot on its line). Solar icon at top right, value '-'. Left icon (battery or device), 6.700 kW (green dot on its line). Right icons (battery storage and a device), values '-'. EV charger icon at bottom left, 31.00 kW. A further device icon at bottom right. Label 'Energy manager' below the house.
5 Add the Wall Connector to Reduxi
Use these steps to add a new Wall Connector or to edit an existing one.
5.1 Basic settings
Log in to the Reduxi Configurator via the browser (see Point 4) and click Add device.
In the first step, enter the basic settings of the device. Then click Next.
5.2 Communication settings
Select the communication channel and enter the advanced settings of the Wall Connector.
5.3 Test communication
Click Test communication at the bottom of the wizard. It reads the Tesla Wall Connector once and saves nothing. If the test succeeds, click Done: only Done creates the device.
Text description of this image
Screenshot of the bottom button bar of a Reduxi Configurator page. Left: button 'Back'. Right: button 'Test communication' (marked with a cyan box) and dark button 'Done'.
Text description of this image
Screenshot of the Reduxi Configurator page 'Communication channel and device configuration'. Connection *: TCP/IP (dropdown). IP *: 192.168.50.243, with button 'Scan for IP'. Port *: 502, with button 'Test port'. Modbus unit ID *: 1. Buttons at the bottom: Back (left), Test communication and Done (right). The Done button is marked with a cyan box.
6 Check the readings
6.1 Last measurements
After communication is established, check the values under Devices in the Reduxi Configurator. Reduxi only reads the Wall Connector.
✓ Summary
Preparation (Points 1–2): Read the Tesla documents and prepare the equipment, including a 2.4 GHz WPA2 Wi‑Fi network.
Wall Connector (Point 3): Install and commission the Wall Connector with the Tesla One app. Set the power management.
Add to Reduxi (Points 4–5): Log in to the Reduxi Configurator, add the device and test the communication.
Go live (Point 6): Check the readings. Reduxi reads the Wall Connector.
→ Common issues
| Issue | Solution |
|---|---|
| The Wall Connector does not join the Wi‑Fi network | It supports only 2.4 GHz networks with WPA2 security (802.11 b/g/n). Check the network type. |
| Network name and password of the Wall Connector are unknown | They are printed on a label at the rear of the unit and on the cover of the Quick Start Guide. |
| Reduxi does not control the Wall Connector | The Tesla Wall Connector Gen 3 is read only in Reduxi. |
| Open configurator does not open or stays empty | The tunnel is not active yet. Wait about 30 seconds and check that the controller is online. |
Login with admin is rejected |
The password was changed during installation. Ask the installer. The Reduxi account password does not work here. |
reduxi.local does not load |
Your device is not in the same network as the controller. Use the IP address or the tunnel connection. |
| Communication test fails, device shows offline | Check reachability, IP address / port / unit ID, and that the protocol is enabled on the device. |
