How to connect AXIbox 11K EV charger with Reduxi controller
Connect the AXIbox 11K charger to Reduxi via Wi‑Fi and the OCPP protocol. Reduxi flexibility allows cost reductions of up to 30%.
Text description of this image
Product photo of a black wall-mounted EV charger on a white background. The front shows a green vertical LED strip, a small card reader symbol with the text CARD, and the printed logo AXITEC. At the bottom front a charging plug sits in a holder; the charging cable hangs from it in two long loops downwards. In the top left corner is a dark square badge with a car and plug icon and the word READY.
1 Prepare
1.1 Technical documentation
- AXIbox 11K product page – AXITEC product page of the charger
- AXIbox 11K datasheet (PDF) – Technical data of the charger
- Installer portal login – Login page named in the original article
1.2 Evchargo app
You configure the charger with the Evchargo app. Install it from the store of your phone:
- Google Play Store: https://play.google.com/store/apps/details?id=cn.enplus.chargein
- Apple App Store: https://apps.apple.com/gb/app/evchargo/id1533765408
Text description of this image
App icon: white rounded square with a green shape formed like a letter E, rounded on the left side with two white horizontal slots cut into it, like a plug.
1.3 Required equipment
- AXIbox 11K charger
- Smartphone with the Evchargo app (Bluetooth is used to find the charger)
- Wi‑Fi network for the charger
- Reduxi Controller in the same network
- Laptop or tablet with internet access to configure the device in Reduxi
2 Configure the AXIbox 11K in the Evchargo app
2.1 Log in or register
Open the app and log in or register a new account. The home page (Welcome page) is displayed.
Text description of this image
Screenshot of the welcome screen of the Evchargo mobile app on a phone (status bar: time 06:55, LTE, battery 90). At the top is a white card with the green heading "Welcome", a green line under it, the grey text "Please select the device to be managed" and a round grey user icon (green person symbol) on the right. Below is a large white card with an illustration of a person holding a phone toward an EV charging station, with a QR code speech bubble above them, trees and clouds. Card title: "Device distribution network management"; subtitle: "I want to configure the network for the charger". The edge of a second white card is visible on the right. The bottom of the screen is empty light grey with the black phone home indicator bar.
2.2 Add group and charger
Once you are logged in, configure the EV charger in the Evchargo app.
Text description of this image
Screenshot of the Charger Group List screen in the Evchargo mobile app on a phone (status bar: time 06:55, LTE, battery 90). Header: back arrow on the left, title "Charger Group List", "Manage" on the right. Below is a search field with the placeholder "Please enter the charger sn, gateway sn, gro..." (text cut off) and a green magnifier icon. The list area is empty: a grey illustration of a charging station with a lightning bolt and a plug, two clouds, and the text "No Data". At the bottom is a wide green rounded button "Add New Group" on a white strip, with the black phone home indicator bar below.
Text description of this image
Screenshot of the Group information screen in the Evchargo mobile app on a phone (status bar: time 06:55, LTE, battery 90). Header: back arrow, title "Group information", "Manage" on the right. A white card lists two fields: Group Name: No Data; Gateway SN: No Data. Below is a grey illustration of a charging station with a lightning bolt and a plug, with two clouds, and the text "No device yet, click "Add new charger" to add". At the bottom: a green round gear icon with the label "Setting" on the left and a wide green button "Add New Charger" on the right, with the black phone home indicator bar below.
Text description of this image
Screenshot of a phone app screen (long image, mostly white below the content) titled Add New Charger with a back arrow on the left. Status bar: time 06:55, LTE signal, battery 90. A blue Bluetooth symbol with the heading Device Bluetooth scanning and the grey text In order to match the charging station more quickly. (cut off). Below, a grey card with one list entry: SN10052204 followed by a blue box that hides the rest of the number, with a chevron arrow on the right. Under the card the text: Unable to find the device, please add a charger (add a charger is a blue link). At the bottom is the phone home indicator bar.
Text description of this image
Screenshot of a phone app screen (very tall, narrow image) titled Manual entry with a back arrow on the left. Status bar: time 06:55, LTE signal, battery 90. Field Charger SN: with the value SN10052204 followed by a blue box that hides the rest, and a green scan frame icon on the right. Field MAC: with the value 78e36df followed by a blue box that hides the rest. Below the fields the screen is empty white. At the bottom: a large green rounded button labelled Add and the phone home indicator bar.
2.3 Connect to Wi‑Fi
Connect the charger to your Wi‑Fi network.
Text description of this image
Screenshot of a phone app screen (long image, mostly white below the content). Status bar: time 06:55, LTE signal, battery 90. Title: Set distribution network information with a back arrow on the left. Field Group Name: Reduxi. Field Wi-Fi: value LBStu followed by a blue box hiding the rest of the network name. Field labelled WIFI Passwor (text cut off as printed): empty. Below the fields the screen is empty white. At the bottom: a large green rounded button labelled distribution network (text as shown) and the phone home indicator bar.
Once the charger is connected to Wi‑Fi, tap the Settings button at the bottom left. Then tap the server information button.
Text description of this image
Screenshot of a phone app screen (long image). Status bar: time 06:57, LTE signal, Wi-Fi symbol, battery 90. Title: Group information with a back arrow on the left and Manage on the right. Card: Group Name: Reduxi; Gateway SN: SN10052204 followed by a blue box hiding the rest, with a green Copy button. Second card: Charger SN: SN10052204 and Gateway SN: SN10052204, each followed by a blue box hiding the rest; a green signal strength icon on the right. Below is an empty light grey area. At the bottom left: a green gear icon with the word Setting; next to it a large green rounded button labelled Add New Charger. The phone home indicator bar is at the very bottom.
Text description of this image
Screenshot of a phone app screen (long image) with a grey dimmed background and a white bottom sheet menu. Status bar: time 06:57, LTE signal, Wi-Fi symbol, battery 90. Title: Group information with a back arrow on the left and Manage on the right. Card: Group Name: Reduxi; Gateway SN: SN10052204 followed by a blue box hiding the rest, with a green Copy button. A second card (dimmed): Charger SN: SN1005220 followed by a blue box; Gateway SN: SN10052204 followed by the blue box; a green signal strength icon on the right. Bottom sheet with the entries, each with a green icon: Update Gateway SN, Server Information, Dismiss Group, Modify Group Name, Upgrade Firmware. The phone home indicator bar is at the very bottom.
2.4 Set the OCPP server
Enter the server information as shown below. You get the OCPP server URL from the Reduxi Controller (see Point 4, section 4.2).
ws://192.168.1.78/ocpp/1.6/json/. Use the URL of your own controller.| Parameter | Value |
|---|---|
| Protocol type | WS |
| IP/Domain |
192.168.1.78 (example: the IP address of your Reduxi Controller) |
| Port |
80 (for the WS protocol) |
| Path | /ocpp/1.6/json/ |
Text description of this image
Screenshot of the Server Information screen in the Evchargo mobile app on a phone (status bar: time 06:42, Wi-Fi, battery 97). Header: back arrow and title "Server Information.". A white card lists the fields: Account Server: Customize (with a right arrow); IP/Domain: 192.168.1.78; Port: 80; Path: /ocpp/1.6/json; Protocol type: WS (No encryption mode) (with a right arrow). Below the card is a wide green button "Confirm" on a light grey background, with the black phone home indicator bar at the bottom.
The last step is the home page of the connected EV charger.
Text description of this image
Screenshot of the home page of a charger app on a phone (long image). Status bar: time 06:42, LTE signal, Wi-Fi symbol, battery 97. Top switch with two options: Self-use (selected, green) and Public. Charger row: green Wi-Fi icon, SN10052204 and a down chevron. Below: a light grey illustration of a wall charger with a green vertical LED line, a card reader symbol and a lightning bolt, with a green ring around it and two lightning bolt buttons on the ring, and a status label Available. Two menu entries with green icons: Max Charging Current with the value 16A and a double chevron; Charging schedule (alarm clock icon) with a double chevron. A large green button labelled Start. Bottom navigation bar: Charge point (selected, green), Map, Me. The phone home indicator bar is at the very bottom.
3 Log in to the Reduxi web interface
You can open the Reduxi web interface in two ways:
Text description of this image
Screenshot of three Reduxi mobile app screens side by side, with cyan boxes and number badges 2 to 4. Left screen (dashboard, dark theme): menu icon at top left marked with a box and badge 2; 'reduxi' logo; tabs 'Real time data' (active) and 'Statistics'; price 5.79 € and temperature 3.2 °C; energy flow diagram with a house in the centre (-1.25 kW) and icons with values 69.0 W, 1.3 kW, 1.1 kW (red ring), -165.0 W with 97 % (red ring) and 0.0 W values at the bottom; tabs 'Power' and 'Energy'; bottom navigation: Dashboard, Diagnostics, Device control, Settings. Middle screen (side menu): 'reduxi' logo, 'Number of locations: 1233', heading 'Reduxi device management', entries '+ Add Reduxi location' and 'Reduxi devices' (marked with a box and badge 3), then 'My profile' and 'About app'. Right screen (device page): Back; picture of a black Reduxi controller with two Ethernet ports; status 'Connected'; card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'; card 'Connect to configurator': 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' with button 'Activate tunnel connection' (marked with a box and badge 4); card 'Unit details' with field 'Unit ID'.
Text description of this image
Screenshot made of two parts side by side. Left part: Reduxi mobile app screen on a dark background. Top: Back button; picture of a black Reduxi controller with two Ethernet ports and a terminal block; status 'Connected' with a Wi-Fi icon. Card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'. Card 'Connect to configurator' with a key icon: 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' and button 'Open configurator', marked with a cyan box and number badge 5. Below: card 'Unit details' with a field 'Unit ID' (value not visible). Right part: Reduxi Configurator opened in a browser, marked with a cyan frame and number badge 6. Header: back arrow, 'Tunnel connection', reload icon. Left sidebar with icons (lightning, chip, lightning bolt, bar chart, gear). Page 'Home' with a green link icon. Green notice: 'New patch available. Click here to apply.' with a close X. Time 09:12:56. Energy flow diagram with a house in the centre (1.700 kW) and icons for grid (0.000 kW), solar (1.700 kW), battery (green, 0.000 kW and 0.800 kW), a device at left (0.900 kW), electric vehicle and a charger or device at bottom. Label 'Energy manager' at the bottom.
http://reduxi.local. You can find the controller's IP address in your router's device list or in the Reduxi app under Reduxi devices.admin · Password: admin (factory default)Text description of this image
Screenshot of the Reduxi Configurator login page in a Chrome browser window. The address bar shows 'Not secure' and 'reduxi.local'; the address bar is marked with a cyan box and an enlarged copy of it (cyan box, text 'Not secure reduxi.local') is shown at the left, connected by a cyan line. Page background: light grey line drawing of a house with solar panels (green), a wall box, an inverter, a car and a charger. Top left: 'reduxi configurator' logo. Login box in the centre with title 'Login', a language selector (English flag, 'English'), a username field and a password field, and a dark 'Login' button.
Text description of this image
Screenshot of the Reduxi Configurator web interface after login, light theme. Top left: 'reduxi configurator' logo. Header bar: 'Home' at left, green 'Connected' status at top right. Left sidebar: expanded section 'Devices' with a list of entries, then collapsed sections 'Manager' and 'Configuration' and 'Settings'. Main area: energy flow diagram. House in the centre with ring, value 24.20 kW. Grid icon at top left, 24.20 kW (red dot on its line). Solar icon at top right, value '-'. Left icon (battery or device), 6.700 kW (green dot on its line). Right icons (battery storage and a device), values '-'. EV charger icon at bottom left, 31.00 kW. A further device icon at bottom right. Label 'Energy manager' below the house.
4 Add the charger to Reduxi
The charger communicates with the Reduxi Controller via OCPP.
4.1 Basic settings
Log in locally to the Reduxi Configurator (see Point 3) and click the Add device button.
Text description of this image
Screenshot of the left sidebar of the Reduxi Configurator. Top: reduxi logo with the text CONFIGURATOR. Collapsed sections: Devices (plus icon) and Strategies (plus icon). Below, two buttons side by side: Add device (plus icon, marked with a blue highlight box) and Add strategy (plus icon). Below them two entries: Settings and Profile. The area to the right of the sidebar is empty white.
In the first step (basic settings), select:
- Device type:
EV charger - Type:
OCPP 1.6 - JSON - Name: a name of your choice
Text description of this image
Screenshot of the Reduxi Configurator add-device wizard, step 1 of 3. Progress bar with three steps: 1 Basic settings (active, black circle), 2 Communication channel (grey), 3 Advanced settings (grey). Heading: Basic settings. Fields: Device type * : empty dropdown; Type * : empty dropdown; Name * : empty text field. Buttons: Back (bottom left), Next (bottom right, dark).
4.2 Communication settings
The second step sets the communication channel for OCPP. First enter the Device identifier. This is the serial number (SN) of the AXIbox 11K. You find it in the Evchargo app.
With OCPP JSON 1.6, the server OCPP URL is generated by the Reduxi Controller. You can read it directly in the communication channel. Enter this URL in the Evchargo app (see Point 2, section 2.4).
ws://192.168.1.78/ocpp/1.6/json/
Text description of this image
Screenshot of the Reduxi Configurator communication settings page in a phone browser (long image). Status bar: time 06:41, LTE signal, Wi-Fi symbol, battery 97. Address bar: 192.168.1.78. The page is dimmed by a dialog. Visible dimmed fields: dropdown with AC; Energy counter: Default; text Allocate power to EVSE when EV is not connected to EVSE; Allow new charging session: Always; Controller OCPP JSON 1.6 URL: ws://192.168.1.78/ocpp/1.6/json with a copy icon. Dialog Test communication with a close x: message in a box Unable to communicate with device. Second box: Number of devices found on OCPP - JSON 1.6: 2; Device identifier: TACW11402 followed by a blue box; Device identifier: SN10052204 followed by the blue box (the SN text is highlighted by a text selection handle). Dialog button: Close. Below the dialog buttons: Back (left), Test communication, Save (right). Footer text: (name omitted) | 6WG4-6TIQ-53W0-131A. The phone home indicator bar overlaps the footer.
4.3 Test communication
Click Test communication at the lower right, below the communication channel fields. It checks that OCPP communication is established and saves nothing. If the test succeeds, click Done: only Done creates the device.
Text description of this image
Screenshot of the Reduxi Configurator add-device wizard, step 2 of 3 (Communication channel). Progress bar: 1 Basic settings (black), 2 Communication channel (black, active), 3 Advanced settings (grey). Heading: Communication channel and device configuration. Fields: Device identifier *: my_station_ID1 (text field being edited, green outline); Connector *: 1; Charger type *: AC; Energy counter: Default; Allocate power to EVSE when EV is not connected to EVSE: Default; Per phase max. current *: Manual override; Per phase max. current manual override: 32 (hint below, small); Forward communication to backend OCPP server: empty; Allow new charging session: Always; Controller OCPP JSON 1.6 URL: ws:// address followed by /ocpp/1.6/json. Buttons at the bottom: Back (left), Test communication (marked with a blue box) and Next (right).
The test returns one of three results:
- Case 1: Communication works properly.
- Case 2: Unable to communicate with device 1. The ID of the device is not set or is different.
- Case 3: No device with OCPP 1.6 communication is found.
Text description of this image
Screenshot of a dialog titled "Test communication" with a close button (x) at top right, over a dimmed form. Green text: "Successful readout from device". Values: Current L1: 0.0 A; Current L2: 0.0 A; Current L3: 0.0 A; Import active power: 0.0 W; Max. active power: 22080.0 W; Max. current per phase: 32.0 A; Min. active power: 0 W; State name: AVAILABLE. Button at bottom right: Close.
Text description of this image
Screenshot of a dialog titled "Test communication" with a close button (x) at top right, over a dimmed form. First box: "Unable to communicate with device." Second box: "Number of devices found on OCPP - JSON 1.6: 1" and "Device identifier: GaroCS-43A4DB2076B80". Button at bottom right: Close. Behind the dialog the dimmed form shows the labels "Energy counter" at the top and "Forward communication to backend OCPP server" at the bottom.
Text description of this image
Screenshot of a dialog titled "Test communication" with a close button (x) at top right, shown over a dimmed page. First box: "Unable to communicate with device." Second box: "Number of devices found on OCPP - JSON 1.6: 0". Button at bottom right: Close.
5 Check the readings
5.1 Last measurements
Check the readings from the device under Device – Last measurement in the Reduxi Configurator.
Text description of this image
Screenshot of the Reduxi Configurator page "Last measurements" of a DAZE charger (per the existing alt text). Card "Control type": a button group Auto (selected, turquoise), Manual, Off, Boost; timestamp 02. 10. 2024 15:47:17. Card "Current": Current L1 0.00 A; Current L2 0.00 A; Current L3 0.00 A; Max. current per phase 32.00 A; Per phase current setpoint 6.00 A (each with timestamp 02. 10. 2024 15:47:17). Card "Power": Import - active power 0.0 kW; Max. active power 22.1 kW; Min. active power 0.0 kW (timestamp 02. 10. 2024 15:47:17). Card "Energy": Import active energy 5,104.5 kWh (timestamp 02. 10. 2024 15:47:17). Card "Other": Communication error OFF (timestamp 02. 10. 2024 15:47:16); Control type AUTO; Error OFF; State name CABLE_UNPLUGGED... (text cut off with dots); timestamps 02. 10. 2024 15:47:17.
Once the device is added in the Configurator, you can monitor it in the Reduxi cloud application.
5.2 Use the charger in a strategy
To reduce energy costs with dynamic prices and dynamic tariffs, define a strategy as described in Strategies for Reduxi controller.
✓ Summary
Preparation (Point 1): Install the Evchargo app and have the charger, a Wi‑Fi network and the Reduxi Controller ready.
AXIbox 11K (Point 2): In the Evchargo app: log in, add the group and charger, connect Wi‑Fi, enter the OCPP server of the controller.
Add to Reduxi (Points 3–4): Log in to the Reduxi web interface. Add an EV charger of type OCPP 1.6 - JSON, enter the device identifier and run Test communication.
Go live (Point 5): Check Last measurement and define a strategy.
→ Common issues
| Issue | Solution |
|---|---|
| Test communication: device ID not set or different (Case 2) | Enter the serial number (SN) of the AXIbox 11K from the Evchargo app as Device identifier. |
| Test communication: no OCPP 1.6 device found (Case 3) | Check the server information in the Evchargo app: protocol WS, IP of the Reduxi Controller, port 80, path /ocpp/1.6/json/. |
| Open configurator does not open or stays empty | The tunnel is not active yet. Wait about 30 seconds and check that the controller is online. |
Login with admin is rejected |
The password was changed during installation. Ask the installer. The Reduxi account password does not work here. |
reduxi.local does not load |
Your device is not in the same network as the controller. Use the IP address or the tunnel connection. |
| Communication test fails, device shows offline | Check reachability, IP address / port / unit ID, and that the protocol is enabled on the device. |
