How to connect Sanxing S34U18 energy meter with Reduxi controller
The Sanxing S34U18 is very similar to the Iskraemeco AM550. Connect it to the Reduxi Controller with the Reduxi P1 converter.
1 Technical documentation
The Sanxing S34U18 is a three-phase electricity meter from Ningbo Sanxing Smart Electric. It is listed as Sanxing SX631 S34U18. The meter is very similar to the Iskraemeco AM550. Reduxi reads it as DLMS-push. According to the E.ON Hungary P1 port document, the meter has a P1 port with an RJ12 connector.
- E.ON Hungary: P1 port interface description – Lists the Sanxing SX631 S34U18 and the P1 port (RJ12 connector)
- ČEZ Distribuce: user manual S34U18 – User manual of the meter (Czech)
2 Required equipment
- Sanxing S34U18 energy meter
- Reduxi P1 converter with the RJ12 cable (the cable is included in the converter package)
- Reduxi Controller
- Laptop or tablet with internet access to configure the device in Reduxi
3 Connect the meter to Reduxi
The energy meter Sanxing S34U18 is very similar to Iskraemeco AM550. Therefore, please follow the following articles:
- Connect P1 converter to Reduxi
- How to add energy meter Iskraemeco AM550
- Reduxi Converter for Iskraemeco AM550 meter
4 Log in to the Reduxi web interface
You can open the Reduxi web interface in two ways:
Text description of this image
Screenshot of three Reduxi mobile app screens side by side, with cyan boxes and number badges 2 to 4. Left screen (dashboard, dark theme): menu icon at top left marked with a box and badge 2; 'reduxi' logo; tabs 'Real time data' (active) and 'Statistics'; price 5.79 € and temperature 3.2 °C; energy flow diagram with a house in the centre (-1.25 kW) and icons with values 69.0 W, 1.3 kW, 1.1 kW (red ring), -165.0 W with 97 % (red ring) and 0.0 W values at the bottom; tabs 'Power' and 'Energy'; bottom navigation: Dashboard, Diagnostics, Device control, Settings. Middle screen (side menu): 'reduxi' logo, 'Number of locations: 1233', heading 'Reduxi device management', entries '+ Add Reduxi location' and 'Reduxi devices' (marked with a box and badge 3), then 'My profile' and 'About app'. Right screen (device page): Back; picture of a black Reduxi controller with two Ethernet ports; status 'Connected'; card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'; card 'Connect to configurator': 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' with button 'Activate tunnel connection' (marked with a box and badge 4); card 'Unit details' with field 'Unit ID'.
Text description of this image
Screenshot made of two parts side by side. Left part: Reduxi mobile app screen on a dark background. Top: Back button; picture of a black Reduxi controller with two Ethernet ports and a terminal block; status 'Connected' with a Wi-Fi icon. Card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'. Card 'Connect to configurator' with a key icon: 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' and button 'Open configurator', marked with a cyan box and number badge 5. Below: card 'Unit details' with a field 'Unit ID' (value not visible). Right part: Reduxi Configurator opened in a browser, marked with a cyan frame and number badge 6. Header: back arrow, 'Tunnel connection', reload icon. Left sidebar with icons (lightning, chip, lightning bolt, bar chart, gear). Page 'Home' with a green link icon. Green notice: 'New patch available. Click here to apply.' with a close X. Time 09:12:56. Energy flow diagram with a house in the centre (1.700 kW) and icons for grid (0.000 kW), solar (1.700 kW), battery (green, 0.000 kW and 0.800 kW), a device at left (0.900 kW), electric vehicle and a charger or device at bottom. Label 'Energy manager' at the bottom.
http://reduxi.local. You can find the controller's IP address in your router's device list or in the Reduxi app under Reduxi devices.admin · Password: admin (factory default)Text description of this image
Screenshot of the Reduxi Configurator login page in a Chrome browser window. The address bar shows 'Not secure' and 'reduxi.local'; the address bar is marked with a cyan box and an enlarged copy of it (cyan box, text 'Not secure reduxi.local') is shown at the left, connected by a cyan line. Page background: light grey line drawing of a house with solar panels (green), a wall box, an inverter, a car and a charger. Top left: 'reduxi configurator' logo. Login box in the centre with title 'Login', a language selector (English flag, 'English'), a username field and a password field, and a dark 'Login' button.
Text description of this image
Screenshot of the Reduxi Configurator web interface after login, light theme. Top left: 'reduxi configurator' logo. Header bar: 'Home' at left, green 'Connected' status at top right. Left sidebar: expanded section 'Devices' with a list of entries, then collapsed sections 'Manager' and 'Configuration' and 'Settings'. Main area: energy flow diagram. House in the centre with ring, value 24.20 kW. Grid icon at top left, 24.20 kW (red dot on its line). Solar icon at top right, value '-'. Left icon (battery or device), 6.700 kW (green dot on its line). Right icons (battery storage and a device), values '-'. EV charger icon at bottom left, 31.00 kW. A further device icon at bottom right. Label 'Energy manager' below the house.
5 Add the Sanxing S34U18 to Reduxi
5.1 Basic settings
Log in to the Reduxi Configurator (see Point 4) and click + Add device. Enter the basic settings:
- Device type:
Energy meter - Type:
Sanxing S34U18 - Name: a name of your choice
5.2 Communication settings
Select the communication channel and enter the device configuration as described in the articles in Point 3.
5.3 Test communication
Click Test communication at the bottom of the wizard. It reads the Sanxing S34U18 once and saves nothing. If the test succeeds, click Done: only Done creates the device.
Text description of this image
Screenshot of the bottom button bar of a Reduxi Configurator page. Left: button 'Back'. Right: button 'Test communication' (marked with a cyan box) and dark button 'Done'.
Text description of this image
Screenshot of the Reduxi Configurator page 'Communication channel and device configuration'. Connection *: TCP/IP (dropdown). IP *: 192.168.50.243, with button 'Scan for IP'. Port *: 502, with button 'Test port'. Modbus unit ID *: 1. Buttons at the bottom: Back (left), Test communication and Done (right). The Done button is marked with a cyan box.
6 Check the readings
6.1 Last measurements
After communication is established, check the values under Devices in the Reduxi Configurator as an additional test.
6.2 Use the meter data in Reduxi
To achieve maximum flexibility and energy cost reduction with dynamic prices and dynamic tariffs, define a strategy as described in Strategies for Reduxi controller.
✓ Summary
Preparation (Points 1–2): Prepare the S34U18 meter, the Reduxi P1 converter with RJ12 cable, the Reduxi Controller and a laptop.
Sanxing S34U18 (Point 3): Follow the articles for the Iskraemeco AM550 and the P1 converter. The meters are very similar.
Add to Reduxi (Points 4–5): Log in to the Reduxi web interface. Add the device as Energy meter, type Sanxing S34U18. Test the communication.
Go live (Point 6): Check the last measurements and use the meter data in your strategy.
→ Common issues
| Issue | Solution |
|---|---|
| Test communication fails | Check the physical connection to the P1 port first. Then follow the troubleshooting steps in the P1 converter article. |
| Open configurator does not open or stays empty | The tunnel is not active yet. Wait about 30 seconds and check that the controller is online. |
Login with admin is rejected |
The password was changed during installation. Ask the installer. The Reduxi account password does not work here. |
reduxi.local does not load |
Your device is not in the same network as the controller. Use the IP address or the tunnel connection. |
| Communication test fails, device shows offline | Check reachability, IP address / port / unit ID, and that the protocol is enabled on the device. |
