How to connect GoodWe hybrid inverters (Dongle, Bluetooth, WiFi, LAN) with Reduxi controller
Connect your GoodWe hybrid inverter to the Reduxi Controller via Modbus TCP. Works with the WiFi/LAN Kit 1.0 and 2.0 over LAN or WiFi.
Text description of this image
Product photo of a white wall-mounted hybrid inverter on a white background, front view. Rounded rectangular white housing with a light grey 'W' logo in the centre of the upper part and screws at the corners. The lower part has a black glass display panel with a row of status icons with tiny labels underneath and a battery level icon with green bars at the right. A small round button is at the left of the panel.
- Technical documentation
- Required equipment
- Choose the connection and enable Modbus TCP
- Configure the WiFi/LAN Kit with the SolarGo app
- Set the static IP with the SEMS+ Classic app
- Update the firmware and check the network (if needed)
- Log in to the Reduxi web interface
- Add the GoodWe inverter to the Reduxi Controller
- Check the readings
- Summary
- Common issues
- Related articles
1 Technical documentation
GoodWe documents for the communication module and the supported devices:
- GoodWe Wi-Fi/LAN Kit Series (WiFi/LAN Kit-20) – Product page of the communication module with datasheet and user manual.
- Compatibility list of GoodWe inverters and IoT products – Shows which inverter works with which communication module and firmware.
2 Required equipment
You need the following components:
- GoodWe hybrid inverter
- GoodWe WiFi/LAN Kit 1.0 or WiFi/LAN Kit 2.0 (communication dongle)
- Reduxi Controller
- Ethernet cable between the inverter and your router or switch
- Smartphone with Bluetooth and the SolarGo app or the SEMS+ Classic app (see Point 4 and Point 5)
- Laptop or tablet with internet access to configure the device in Reduxi
3 Choose the connection and enable Modbus TCP
Modbus TCP communication with Reduxi depends on the dongle and on how the inverter is connected to the Internet. Find your case:
| Dongle and connection | Modbus TCP | Next step |
|---|---|---|
| WiFi/LAN Kit 1.0 via LAN | Enabled automatically | Set a static IP with the SEMS+ Classic app (Point 5) |
| WiFi/LAN Kit 1.0 via WiFi | Enable it with the SolarGo app | Configure the dongle with SolarGo (Point 4) |
| WiFi/LAN Kit 2.0 via LAN | Enabled automatically | Check the serial number (Point 3.5) |
| WiFi/LAN Kit 2.0 via WiFi | Activation by GoodWe After-Sale Support | Send the e-mail (Point 3.4), then check the serial number (Point 3.5) |
3.1 WiFi/LAN Kit 1.0 via LAN
Text description of this image
Photo of a black GoodWe WiFi/LAN Kit 1.0 dongle on a white background. It is a tall rounded black module with a connector plug at the top, a small dark display window in the middle, and a logo and a network (LAN) symbol printed below it. Two indicator lights are at the bottom: a blue one on the left and a green one on the right, each with a small printed symbol.
The inverter is connected to the Internet with the WiFi/LAN Kit 1.0 via LAN. Modbus TCP is enabled automatically with these settings:
- Device ID:
1 - Port:
502 - Baud rate:
9600
Continue with Point 5, Set the static IP with the SEMS+ Classic app.
3.2 WiFi/LAN Kit 1.0 via WiFi
Text description of this image
Photo of a black GoodWe WiFi/LAN Kit 1.0 dongle on a white background. It is a tall rounded black module with a connector plug at the top, a small dark display window in the middle, and a logo and a network (LAN) symbol printed below it. Two indicator lights are at the bottom: a blue one on the left and a green one on the right, each with a small printed symbol.
The inverter is connected to the Internet with the WiFi/LAN Kit 1.0 via WiFi. You must enable Modbus TCP with the SolarGo app.
Continue with Point 4, Configure the WiFi/LAN Kit with the SolarGo app.
3.3 WiFi/LAN Kit 2.0 via LAN
Text description of this image
Photo of a black GoodWe WiFi/LAN Kit 2.0 dongle on a white background. A red diagonal ribbon across the top reads NEW. The dongle has a connector plug at the bottom, a small dark display window in the upper part and a logo and network symbol below it. Two small indicator lights are visible near the lower part, one blue and one green/yellow.
The inverter is connected to the Internet with the WiFi/LAN Kit 2.0 via LAN. Modbus TCP is enabled automatically with these settings:
- Device ID:
1 - Port:
502 - Baud rate:
9600
Continue with Point 3.5, Serial number of the WiFi/LAN Kit 2.0.
3.4 WiFi/LAN Kit 2.0 via WiFi
Text description of this image
Photo of a black GoodWe WiFi/LAN Kit 2.0 dongle on a white background. A red diagonal ribbon across the top reads NEW. The dongle has a connector plug at the bottom, a small dark display window in the upper part and a logo and network symbol below it. Two small indicator lights are visible near the lower part, one blue and one green/yellow.
The inverter is connected to the Internet with the WiFi/LAN Kit 2.0 via WiFi. GoodWe After-Sale Support must activate Modbus TCP. Send an e-mail to service.se@goodwe.com:
- Subject: Enable MODBUS TCP for WLAN/LAN 2.0 dongle
- Inverter serial number
- Dongle serial number
After GoodWe has activated Modbus TCP, continue with Point 3.5.
3.5 Serial number of the WiFi/LAN Kit 2.0
The WiFi/LAN Kit 2.0 exists as a regular version and as a version with cyber security. Check the serial number on the dongle:
- Serial number starts with
72000: regular version. - Serial number starts with
72100: version with cyber security. You must make additional settings on the inverter. Follow the steps in Point 4.
72000…
Text description of this image
Photo of a black GoodWe WiFi/LAN Kit dongle lying on a light grey surface. A white label on it shows the text WiFi Kit-20, a barcode and the serial number 72000WFA23500051. A connector plug is at the left end of the dongle.
4 Configure the WiFi/LAN Kit with the SolarGo app
4.1 Download and install the SolarGo app (if needed)
Text description of this image
Image with two parts on a white background. Top: black badge reading Download on the App Store with the Apple logo. Below it: a black and white QR code. Per the caption, the QR code links to the SolarGo app in the App Store.
Text description of this image
Black badge 'GET IT ON Google Play' with the Google Play triangle logo, and below it a black and white QR code for the SolarGo app download.
4.2 Connect to the inverter via Bluetooth
Make sure the inverter is switched on and that the inverter and the communication module work properly.
Text description of this image
Three phone screenshots side by side of the Device List screen of the SolarGo app, with numbered blue badges and red outlines. Header of each: 'Device List' with a cloud icon, a help icon and a menu icon; tabs Bluetooth (selected) and WLAN. Screenshot 1: the Bluetooth tab is outlined in red (badge 1); empty state with an illustration of devices and the text 'No Device'; the button 'Search Device' is outlined in red (badge 2); link 'Not Found >'. Screenshot 2: list of found devices with a chevron each, names: CCM-4050KNAC248G0001 (with a 'Parallel' icon), WLA-5012KNAG24BL0005 (outlined in red, badge 3), WNN-52000MIA226W5006, SOL-BLE244L8002, WFA-96000ETF225W6666, GSA-8010KMSF226G8006; button 'Search Device'; link 'Not Found >'. Screenshot 3 (greyed background): list with CCM-23000EZL21B50020 and CCM-53000SSA238GS019, and an iPhone dialog 'Bluetooth Pairing Request' with the text that a device would like to pair with your iPhone, and buttons Cancel and Pair (Pair outlined in red, badge 4).
1234. If the password has already been changed, use your chosen password. A reminder to change the password appears only when necessary. Change the password if you have not done so yet.Text description of this image
Composite of SolarGo app screens with red outlines, numbered blue badges 5 to 8 and red arrows showing the order. Badge 5 (top left): login dialog over a greyed device list with two role icons, Owner and Installer (Installer selected), an empty password field with an eye icon (no value shown), a ticked checkbox 'Remember Password' and a button 'Login'. Red arrow down to badge 6: dialog 'Reminder' with the text 'To keep your account secure, you must change your password now.' and the link 'I am aware of that'. Red arrow down to badge 7: dialog 'Change Password' with two empty password fields with eye icons, the note 'Note:8-16 characters, including digits, uppercase letters or lowercase letters.' and a button 'YES'. Red arrow right to badge 8 (right): screen 'Device List' with tabs Bluetooth (selected) and WLAN, a list of devices (CCM-, WLA-.), and the same login dialog as badge 5 (Owner/Installer, empty password field, ticked 'Remember Password', 'Login'); at the bottom the button 'Search Device' and link 'Not Found >'.
Text description of this image
Screenshot of the main page of the SolarGo app on a phone. Header: back arrow and a device number beginning with 9015. Status pill: 'Status:Normal (On-Grid)'. Energy flow diagram, 'Unit:kW': solar panel icon with flow value 13.25 towards a house icon with 13.25; battery icon 100% with value 0.00; grid pylon icon with value 0.00. Info tiles: Safety Power Grid Code: Warehouse; Working Mode: Peak Shaving; Battery Model: LX F16.0-H-20; Battery Status: Normal; Backup: ON; Power Limit: OFF. Bottom navigation: Home (selected, blue), Parameters, Settings.
4.3 Enable and configure Modbus TCP
The Modbus TCP settings depend on the dongle. Check the serial number first (see Point 3, Point 3.5).
Regular dongle: serial number starts with 72000
Text description of this image
Three phone screens side by side from the SolarGo app, connected by red lines and arrows. Screen 1, Settings: Communication Settings (red box), Quick Settings, Basic Settings, Advanced Settings, Port Connection, Meter/CT-Assisted Test, Firmware Information, APP Version; bottom tabs Home, Parameters, Settings (Settings marked with a red box). Screen 2, Communication Settings: WLAN/LAN, WLAN Detection, 4G, RS485 (RS485 in a red box, arrow from Communication Settings to it). Screen 3, RS485 (title in a red box): Modbus TCP with a green toggle switched on (red box); COM Address: 0 with a blue check button, and a faint range hint; Baud Rate: dropdown, empty.
- Device ID:
1 - Port:
502 - Baud rate:
9600
Cyber security dongle: serial number starts with 72100
Text description of this image
Three phone screenshots of the SolarGo app side by side, joined by red arrows. Left, 'Settings' list: Communication Settings (outlined in red), Quick Settings, Basic Settings, Advanced Settings, Port Connection, Meter/CT-Assisted Test, Firmware Information, 'APP Version: V5.6.0'; bottom navigation Home, Parameters, Settings (outlined in red). Middle, 'Communication Settings' list: Privacy & Security (outlined in red), WLAN/LAN, 4G, RS485. Right, 'Privacy & Security' page with three sections. Section Bluetooth: toggle 'Bluetooth Stays On' (off) with text: ON: the APP can continuously access devices through Bluetooth; OFF: the APP will not be able to access the device through Bluetooth; if the APP cannot search for the Bluetooth signal of the device, double-click the 'RELOAD' button on the communication module to turn on the Bluetooth signal, and use the APP to connect to the device within 5 minutes. Section WLAN: toggle 'WLAN Control' (off) with text: ON: the APP can connect devices through the WLAN local area network of the communication module; OFF: the APP cannot connect to the device through the WLAN local area network of the communication module. Section Modbus TCP: toggle 'Modbus TCP' (off), outlined in a red rectangle, with text 'ON: A third-party platform that can access inverter information through communication protocols. You can contact after-sales service to obtain the agreement.'
- Device ID:
1 - Port:
502 - Baud rate:
9600
4.4 Set a static IP address
Set the IP address of the inverter. We recommend a fixed (static) IP address.
Text description of this image
Three phone screens side by side from the SolarGo app, connected by red arrows. Screen 1, Settings: entries Communication Settings (red box, highlighted), Quick Settings, Basic Settings, Advanced Settings, Port Connection, Meter/CT-Assisted Test, Firmware Information, APP Version V5.8.0; bottom tabs Home, Parameters, Settings (Settings marked with a red box). Screen 2, Communication Settings: Privacy & Security, WLAN/LAN (red box, highlighted), 4G, RS485. Screen 3, WLAN/LAN with a Save link at top right: Encryption Type: WPA2/WPA; Password: field, value not shown; a red box around DHCP with a green toggle that appears switched on, and the hint: If you need to set a specific IP address, you can manually enter it after turning off DHCP; then IP Address, Subnet Mask, Gateway Address, DNS Server. Below the box: LAN: Not Connected, and a blue link: Restore factory communication settings.
5 Set the static IP with the SEMS+ Classic app
5.1 Download and install the SEMS+ Classic app (if needed)
Text description of this image
Image with two parts on a white background. Top: black badge reading Download on the App Store with the Apple logo. Below it: a black and white QR code with a thin light grey border. Per the caption, the QR code links to the SEMS+ Classic app in the App Store.
Text description of this image
Image with two parts on a white background. Top: black badge reading GET IT ON Google Play with the coloured Google Play triangle logo. Below it: a black and white QR code. The QR code links to the SEMS+ Classic app on Google Play according to the caption.
5.2 Connect to the inverter via Bluetooth and set the IP
Make sure the inverter is switched on and that the inverter and the communication module work properly.
Text description of this image
Three phone screenshots side by side from the SEMS+ app (GoodWe), with red ovals and numbers 1, 2 and 3. Screenshot 1 (time 14:49): home screen with a banner 'Test' showing a white inverter; section 'Services' with tiles Warranty, Report Center, GoodWe News, Announcements; section 'Tools' with the tile 'Network Link' circled in red and marked 1; section 'Help'. Screenshot 2 (time 14:47): title 'Network Link' with tabs Bluetooth (selected) and WLAN, and a list of devices: LEM-23000LEM21B55890, WLA-96000NAW253L0008 (circled in red and marked 2), LEM-23000LEM25318015, WFA-40800EAA238W0010, LEM-23000LEM21B55898, WLA-5110KNZ500008888, WLA-8100KHTU201R0001. Screenshot 3 (time 14:47): a pairing prompt with 'Cancel' at the top right, two icons User (selected) and Installer, a password input field with the placeholder 'Please enter a password' and an eye icon, and a checkbox 'Remember Password' (not ticked); the field area is circled in red and marked 3. Below it a hint text says that if the password is forgotten, press and hold the bluetooth button on the device to restore the default password (the default value is shown in the image and is left out here), or Contact Us.
1234. If the password has already been changed, use your chosen password. A reminder appears only when necessary. Change the password if you have not done so yet. Activate Remember Password and continue.Text description of this image
Screenshot of the 'Network Link' page of the SEMS+ app on a phone, framed by a red rectangle with the red number 4. Status bar: time 14:47, mute icon, signal, Wi-Fi, battery 64. Header: back arrow, title 'Network Link' and a Bluetooth icon (blue) at the right. Three list rows, each with a chevron: Privacy & Security, WLAN/LAN, Login Password Change. The rest of the page is empty light blue, with a black home indicator bar at the bottom.
Text description of this image
Two phone screenshots side by side from the SEMS+ app, WLAN/LAN screen, with red outlines and red number labels 5, 6 and 7. Left screen: LAN: Not Connected; WLAN: on (toggle); Name: a Wi-Fi network name (H3C_2D63E5); Encryption Method: WPA2; Password: field with a dropdown arrow, value not shown. Red box 5 marks DHCP Automatic Obtain, toggle on, with the hint text that to set a specified IP address you turn off DHCP Automatic Obtain and use Manual Setting. Red box 6 marks the fields IP Address, Subnet Mask, Gateway Address and DNS Server, with greyed values. Below them is a WLAN Detection button and the note: When LAN and WLAN are configured simultaneously, the communication will prioritize LAN. Right screen: same screen dimmed, with a WLAN Detection popup (red box 7) and a Cancel link. The popup shows three icons (inverter, router, cloud) joined by blue check marks and the text: Network configuration successful.
6 Update the firmware and check the network (if needed)
6.1 Update the inverter firmware
If you have any problems, update the inverter firmware to the latest version.
Text description of this image
Two phone screenshots side by side from the SolarGo/SEMS+ app, joined by a red arrow. Left, 'Settings' list: Communication Settings, Basic Settings, Advanced Settings, Load Control, Power on/off, Firmware Information (outlined in red; the red arrow starts here), Change Login Password; each with a chevron. Bottom navigation: Home, Parameters, Settings (outlined in red, selected). Right, 'Firmware Information' page with a back arrow: DSP FW Version; ARM FW Version; Communication Module FW Version. Text 'Tips: Please keep the mobile cloud network normal to obtain the latest firmware version information.' Blue link 'Check For Update' with a red dashed outline.
6.2 Configure the network
Connect the inverter to the Internet with an Ethernet cable. Only then can the inverter communicate with the Reduxi Controller via Modbus TCP.
Modbus TCP: tap Settings, then Privacy & Security, and enable Modbus TCP. Then set:
- Device ID:
1 - Port:
502 - Baud rate:
9600
Static IP address: tap Settings, then WLAN/LAN. If the DHCP switch is on, switch it off and enter the data that fits your network manually. We recommend a fixed (static) IP address. Write down the IP address for later. The screens are the same as in Point 4, Points 4.3 and 4.4.
7 Log in to the Reduxi web interface
You can open the Reduxi web interface in two ways:
Text description of this image
Screenshot of three Reduxi mobile app screens side by side, with cyan boxes and number badges 2 to 4. Left screen (dashboard, dark theme): menu icon at top left marked with a box and badge 2; 'reduxi' logo; tabs 'Real time data' (active) and 'Statistics'; price 5.79 € and temperature 3.2 °C; energy flow diagram with a house in the centre (-1.25 kW) and icons with values 69.0 W, 1.3 kW, 1.1 kW (red ring), -165.0 W with 97 % (red ring) and 0.0 W values at the bottom; tabs 'Power' and 'Energy'; bottom navigation: Dashboard, Diagnostics, Device control, Settings. Middle screen (side menu): 'reduxi' logo, 'Number of locations: 1233', heading 'Reduxi device management', entries '+ Add Reduxi location' and 'Reduxi devices' (marked with a box and badge 3), then 'My profile' and 'About app'. Right screen (device page): Back; picture of a black Reduxi controller with two Ethernet ports; status 'Connected'; card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'; card 'Connect to configurator': 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' with button 'Activate tunnel connection' (marked with a box and badge 4); card 'Unit details' with field 'Unit ID'.
Text description of this image
Screenshot made of two parts side by side. Left part: Reduxi mobile app screen on a dark background. Top: Back button; picture of a black Reduxi controller with two Ethernet ports and a terminal block; status 'Connected' with a Wi-Fi icon. Card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'. Card 'Connect to configurator' with a key icon: 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' and button 'Open configurator', marked with a cyan box and number badge 5. Below: card 'Unit details' with a field 'Unit ID' (value not visible). Right part: Reduxi Configurator opened in a browser, marked with a cyan frame and number badge 6. Header: back arrow, 'Tunnel connection', reload icon. Left sidebar with icons (lightning, chip, lightning bolt, bar chart, gear). Page 'Home' with a green link icon. Green notice: 'New patch available. Click here to apply.' with a close X. Time 09:12:56. Energy flow diagram with a house in the centre (1.700 kW) and icons for grid (0.000 kW), solar (1.700 kW), battery (green, 0.000 kW and 0.800 kW), a device at left (0.900 kW), electric vehicle and a charger or device at bottom. Label 'Energy manager' at the bottom.
http://reduxi.local. You can find the controller's IP address in your router's device list or in the Reduxi app under Reduxi devices.admin · Password: admin (factory default)Text description of this image
Screenshot of the Reduxi Configurator login page in a Chrome browser window. The address bar shows 'Not secure' and 'reduxi.local'; the address bar is marked with a cyan box and an enlarged copy of it (cyan box, text 'Not secure reduxi.local') is shown at the left, connected by a cyan line. Page background: light grey line drawing of a house with solar panels (green), a wall box, an inverter, a car and a charger. Top left: 'reduxi configurator' logo. Login box in the centre with title 'Login', a language selector (English flag, 'English'), a username field and a password field, and a dark 'Login' button.
Text description of this image
Screenshot of the Reduxi Configurator web interface after login, light theme. Top left: 'reduxi configurator' logo. Header bar: 'Home' at left, green 'Connected' status at top right. Left sidebar: expanded section 'Devices' with a list of entries, then collapsed sections 'Manager' and 'Configuration' and 'Settings'. Main area: energy flow diagram. House in the centre with ring, value 24.20 kW. Grid icon at top left, 24.20 kW (red dot on its line). Solar icon at top right, value '-'. Left icon (battery or device), 6.700 kW (green dot on its line). Right icons (battery storage and a device), values '-'. EV charger icon at bottom left, 31.00 kW. A further device icon at bottom right. Label 'Energy manager' below the house.
8 Add the GoodWe inverter to the Reduxi Controller
Connect the Reduxi Controller and the hybrid inverter via Ethernet. Then register the inverter as a new device (GoodWe hybrid inverter).
8.1 Basic settings
Log in locally to the Reduxi Configurator on the controller (see Point 7) and click + Add device.
Text description of this image
Screenshot of the Reduxi Configurator sidebar. Header: reduxi Configurator logo. Section Devices (with a minus icon) lists: BYD 24kWh; Iskraemeco AM550; Ochsner GMLW 9Plus; SolarEdge Master; SolarEdge Slave. At the bottom is an Add device button with a plus sign, marked with a red rectangle.
In the first step (basic settings), select the basic parameters of the device:
- Device type:
Hybrid inverter - Type:
GoodWe Energy Storage Inverters HV - Name: a name of your choice
Text description of this image
Screenshot of the Reduxi Configurator, step 1 of 2 Basic settings. Step indicator: 1 Basic settings (active, black), 2 Communication channel (grey). Form titled Basic settings: Device type (required): Hybrid inverter; Type (required): GoodWe Energy Storage Inverters HV; Name (required): GoodWe Energy Storage Inverters HV. Buttons: Back (left), Next (right, dark).
Press Next.
8.2 Communication settings
The second step sets up the communication channel for Modbus TCP. It links the Reduxi Controller with the GoodWe hybrid inverter. Enter the IP address of the inverter that you set earlier (see Point 4, Point 4.4, or Point 5).
| Parameter | Value |
|---|---|
| Connection | TCP/IP |
| IP | The static IP address you set on the inverter |
| Port | 502 |
| Modbus unit ID | Default 247 (as shown in the Configurator) |
| Control mode | Default EMS (as shown in the Configurator) |
Text description of this image
Screenshot of the Reduxi Configurator communication settings form for the GoodWe hybrid inverter. Fields: Connection (required): TCP/IP; IP (required): empty; Port (required): 502; Modbus unit ID (required): 247; Control mode (required): EMS, with the hint text below it: Select control mode of inverter. Buttons at the bottom: Back (left), Test communication and Done (right, dark).
8.3 Test communication
Click Test communication at the bottom of the wizard. It reads the GoodWe hybrid inverter once and saves nothing. If the test succeeds, click Done: only Done creates the device.
Text description of this image
Screenshot of the bottom button bar of a Reduxi Configurator page. Left: button 'Back'. Right: button 'Test communication' (marked with a cyan box) and dark button 'Done'.
Text description of this image
Screenshot of the Reduxi Configurator page 'Communication channel and device configuration'. Connection *: TCP/IP (dropdown). IP *: 192.168.50.243, with button 'Scan for IP'. Port *: 502, with button 'Test port'. Modbus unit ID *: 1. Buttons at the bottom: Back (left), Test communication and Done (right). The Done button is marked with a cyan box.
Example of a successful readout:
Text description of this image
Screenshot of a dialog titled Test communication (close x at the top right) with green text. Content: Successful readout from device. Values: Battery active power: -450.0 W; Battery current: -1.8 A; Battery export active energy: 2493400 Wh; Battery import active energy: 2784800 Wh; Battery max. active power: 10000.0 W; Battery min. active power: -10000.0 W; Battery state of charge: 25.63 %; Battery state of health: 99.37 %; Battery voltage: 269.5 V; Error: false; Grid export active energy: 0 Wh; Grid import active energy: 0 Wh; Inverter active power: -1444 W; Load active power: 76 W; Load import active energy: 953900 Wh; Off-grid: false; PV active power: -839 W; PV current: -1.9 A; PV export active energy: 10434800 Wh; PV min. active power: -10000 W; PV voltage: 433.7 V; State name: ON_GRID. Additional parameters: GRID_POWER_ACTIVE_L1: 20; GRID_POWER_ACTIVE_L2: 12; GRID_POWER_ACTIVE_L3: 24; PV_POWER_ACTIVE_MAX: 0. Dark button at the bottom right: Close.
9 Check the readings
9.1 Last measurements
Check the readings under Devices – GoodWe Hybrid Inverter – Last measurements in the Reduxi Configurator.
Text description of this image
Screenshot of the Reduxi Configurator, page 'Last measurements' of the device 'GoodWe Hybrid Inverter ESG2 6kW 1ph'. Left sidebar: logo 'reduxi Configurator'; section Devices with entries 'GoodWe Hybrid Inverter ESG2 6kW 1ph' (active), MasterTherm, Reduxi Meter; then 'Optimization modes' (plus sign) and 'Utility Rate Plan'. Top: breadcrumb 'Device / GoodWe Hybrid Inverter ESG2 6kW 1ph', a green link icon, and a banner 'New patch available. Click here to apply.' with a close x. Tabs: Last measurements (active), Analyze, Archive; refresh dropdown 'Each second'. Tile 'Control type': buttons Auto (light green, selected) and Manual (dark); timestamp 07. 05. 2025 12:17:41. Card Battery (timestamps 07. 05. 2025 12:19:22): Battery active power 0.0 kW; Battery current 0.30 A; Battery voltage 53.20 V; Battery capacity (Wh) 16.3 kWh; Battery maximum capacity (Wh) 22.3 kWh; Battery state of charge 73.00 %; Battery state of health 100.00 %; Battery min. state of charge 10.00 % (cut off at the bottom of the image). Card PV (12:19:23): PV active power -1.3 kW; PV current -3.40 A; PV voltage 374.60 V; PV export active energy 3,306.8 kWh; PV min. active power -6.1 kW. Card Load (12:19:22): Load active power 1.3 kW; Load import active energy 26,830.9 kWh.
After the device is added in the Configurator, you can also monitor it in the Reduxi cloud application.
9.2 Enable control by Reduxi
For control by Reduxi, set the control type to AUTO under Devices – GoodWe Hybrid Inverter in the Reduxi Configurator. Only then do strategy commands affect the inverter.
To reduce energy costs with dynamic prices and dynamic tariffs, define a strategy as described in Strategies for Reduxi controller.
✓ Summary
Preparation (Points 1–3): Check the documents and the equipment. Choose your dongle and connection and enable Modbus TCP (Point 3).
GoodWe inverter (Points 4–6): Configure the dongle with SolarGo or set the static IP with SEMS+ Classic. Write down the IP address. Update the firmware if needed.
Add to Reduxi (Points 7–8): Log in to the Reduxi web interface. Add the device as Hybrid inverter, type GoodWe Energy Storage Inverters HV. Enter the IP and port 502. Run Test communication, then click Done.
Go live (Point 9): Check the last measurements. Set the control type to AUTO.
→ Common issues
| Issue | Solution |
|---|---|
| Test communication fails | Check the IP address of the inverter, port 502 and that Modbus TCP is enabled. Check that the inverter is connected via Ethernet and in the same network as the controller. |
| Modbus TCP is not available with WiFi/LAN Kit 2.0 via WiFi | GoodWe After-Sale Support must activate it. Send the e-mail described in Point 3.4. |
| Dongle serial number starts with 72100 | Enable Modbus TCP under Settings – Privacy & Security (Point 4.3). |
| The inverter IP address changes | Switch off DHCP and set a static IP address (Point 4.4 or Point 5.2). |
| Communication problems persist | Update the inverter firmware (Point 6.1). |
| Open configurator does not open or stays empty | The tunnel is not active yet. Wait about 30 seconds and check that the controller is online. |
Login with admin is rejected |
The password was changed during installation. Ask the installer. The Reduxi account password does not work here. |
reduxi.local does not load |
Your device is not in the same network as the controller. Use the IP address or the tunnel connection. |
| Communication test fails, device shows offline | Check reachability, IP address / port / unit ID, and that the protocol is enabled on the device. |
