How to connect AlphaESS Smile Hybrid Series with Reduxi controller
Cut energy costs by up to 70%: Reduxi integrates AlphaESS Smile series hybrid inverters via Modbus TCP/IP or RTU.
Text description of this image
Logo of AlphaESS with the tagline your smart energy. At the left a stylised letter A made of grey, black, green and yellow shapes; at the right the word AlphaESS in dark grey and below it the text your smart energy.
1 Technical documentation
Manufacturer documents for the AlphaESS Smile series:
- AlphaESS SMILE-G3 three phase 4/6/8/10 kW – Product page from the manufacturer
- Datasheet SMILE-G3-S3.6/S5/B5 – PDF, EN
- Datasheet SMILE-G3-T4/T5/T6/T8/T10 – PDF, EN
2 Required equipment
Prepare the following, depending on the connection you use:
- Reduxi Controller (installed and online)
- AlphaESS Smile hybrid inverter with the latest firmware
- Modbus TCP/IP via LAN: Ethernet cable to the inverter
- Modbus TCP/IP via Wi-Fi: Wi‑Fi dongle with the latest firmware
- Modbus RTU: Ethernet cable with RJ45 connector for the RS 485 wires (see Point 3)
- Laptop or tablet with internet access to configure the device in Reduxi
3 Connect the Reduxi Controller to the inverter
Choose one of three connections, depending on how the system was installed:
- Modbus TCP/IP via LAN cable
- Modbus TCP/IP via Wi‑Fi dongle
- Modbus RTU
3.1 Modbus TCP/IP via LAN
The picture shows the entire connection from the Reduxi Controller to the inverter.
Text description of this image
Diagram of the connection via LAN cable. Components: Reduxi Controller (grey box with reduxi logo, label 'Controller'); Router (white Wi-Fi router, label 'Router'); WWW globe icon (internet); Hybrid Inverter (white AlphaESS unit with battery stack, label 'Hybrid Inverter'). Connections: Controller to Router: solid cyan line labelled 'Ethernet'; Router to Hybrid Inverter: solid cyan line labelled 'Ethernet'; Router to Internet (WWW): dashed cyan line.
To perform the update, contact AlphaESS support by e-mail: info@alpha-ess.com
3.2 Modbus TCP/IP via Wi‑Fi
The picture shows the entire connection from the Reduxi Controller to the inverter.
Text description of this image
Diagram of the connection via Wi-Fi dongle. Components: Reduxi Controller (grey box with reduxi logo, label 'Controller'); Router (white Wi-Fi router, label 'Router'); WWW globe icon (internet); AlphaESS Wi-Fi Dongle (black dongle, label 'AlphaESS WiFi Dongle', with a red exclamation mark next to it); Hybrid Inverter (white AlphaESS unit with battery stack, label 'Hybrid Inverter'). Connections: Controller to Router: solid cyan line labelled 'Ethernet'; Router to Internet (WWW): dashed cyan line; Router to AlphaESS Wi-Fi Dongle: solid cyan line labelled 'WiFi'; Dongle to Hybrid Inverter: short cyan line.
To perform the update, contact AlphaESS support by e-mail: info@alpha-ess.com
3.3 Modbus RTU
The picture shows the entire connection from the Reduxi Controller to the inverter.
Text description of this image
Diagram of the connection via Modbus RTU. Components: Reduxi Controller (grey box with reduxi logo, label 'Controller'); Router (white Wi-Fi router, label 'Router'); WWW globe icon (internet); Hybrid Inverter (white AlphaESS unit with battery stack, label 'Hybrid Inverter'). Connections: Router to Controller: solid cyan line labelled 'Ethernet'; Controller to Hybrid Inverter: solid cyan line labelled 'RS 485 A/B'; Router to Internet (WWW): dashed cyan line.
Wiring by series:
AlphaESS Smile B series
| Reduxi Controller | Wire colour (controller) | Wire colour (inverter) | AlphaESS inverter |
|---|---|---|---|
| Ethernet cable | Ethernet RJ45 connector | ||
| RS 485 + | Blue/White | Blue/White | Pin 5 |
| RS 485 - | Blue | Blue | Pin 4 |
Text description of this image
Wiring diagram for the AlphaESS Smile B series. Left: 'Reduxi Controller' with a 4-pin terminal block labelled 'RS485'. Above it the terminal strip is labelled GND, A, B, 5VDC; terminals A and B are enclosed in a red box. A black line runs from A and B to the inverter on the right. Right: a magnified circle of the inverter's connector list with entries PV_CT, D2-INV, DRM, CT/METER/D1, LAN, BMS and CAN/RS485; the CAN/RS485 entry is circled in red and the wire from A and B ends there. A red arrow links the circle to the inverter housing drawing, where the connector area is circled in red.
AlphaESS Smile G series
| Reduxi Controller | Wire colour (controller) | Wire colour (inverter) | AlphaESS inverter |
|---|---|---|---|
| Ethernet cable | Ethernet RJ45 connector | ||
| RS 485 + | Blue/White | Blue/White | Pin 5 |
| RS 485 - | Blue | Blue | Pin 4 |
Text description of this image
Wiring diagram for the AlphaESS Smile G series. Left: 'Reduxi Controller' with a 4-pin terminal block labelled 'RS485'. Above it the terminal strip is labelled GND, A, B, 5VDC; terminals A and B are enclosed in a red box. A black line runs from A and B to a connector in the inverter. Right: a magnified oval view of a connector block on the inverter with a small port at the top and several RJ45-style ports; the wire ends at one of the ports, circled in red. Red lines link the oval to the inverter drawing on the right, where two port groups at the right side are circled in red; labels on the inverter drawing.
AlphaESS Smile T-10 series
| Reduxi Controller | Wire colour (controller) | Wire colour (inverter) | AlphaESS inverter |
|---|---|---|---|
| Ethernet cable | Ethernet RJ45 connector | ||
| RS 485 + | Blue/White | Blue/White | Pin 5 |
| RS 485 - | Blue | Blue | Pin 4 |
Text description of this image
Wiring diagram for the AlphaESS Smile T-10 series. Left: 'Reduxi Controller' with a 4-pin terminal block labelled 'RS485'. Above it the terminal strip is labelled GND, A, B, 5VDC; terminals A and B are enclosed in a red box. A black line runs from A and B to a red-framed box labelled 'Dispatch' showing an RJ45-type socket. A red line leads from this box to a red circle on the inverter drawing on the right, marking the port where the cable connects.
To perform the update, contact AlphaESS support by e-mail: info@alpha-ess.com
When the update is complete, continue with Point 4.
4 Log in to the Reduxi web interface
You can open the Reduxi web interface in two ways:
Text description of this image
Screenshot of three Reduxi mobile app screens side by side, with cyan boxes and number badges 2 to 4. Left screen (dashboard, dark theme): menu icon at top left marked with a box and badge 2; 'reduxi' logo; tabs 'Real time data' (active) and 'Statistics'; price 5.79 € and temperature 3.2 °C; energy flow diagram with a house in the centre (-1.25 kW) and icons with values 69.0 W, 1.3 kW, 1.1 kW (red ring), -165.0 W with 97 % (red ring) and 0.0 W values at the bottom; tabs 'Power' and 'Energy'; bottom navigation: Dashboard, Diagnostics, Device control, Settings. Middle screen (side menu): 'reduxi' logo, 'Number of locations: 1233', heading 'Reduxi device management', entries '+ Add Reduxi location' and 'Reduxi devices' (marked with a box and badge 3), then 'My profile' and 'About app'. Right screen (device page): Back; picture of a black Reduxi controller with two Ethernet ports; status 'Connected'; card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'; card 'Connect to configurator': 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' with button 'Activate tunnel connection' (marked with a box and badge 4); card 'Unit details' with field 'Unit ID'.
Text description of this image
Screenshot made of two parts side by side. Left part: Reduxi mobile app screen on a dark background. Top: Back button; picture of a black Reduxi controller with two Ethernet ports and a terminal block; status 'Connected' with a Wi-Fi icon. Card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'. Card 'Connect to configurator' with a key icon: 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' and button 'Open configurator', marked with a cyan box and number badge 5. Below: card 'Unit details' with a field 'Unit ID' (value not visible). Right part: Reduxi Configurator opened in a browser, marked with a cyan frame and number badge 6. Header: back arrow, 'Tunnel connection', reload icon. Left sidebar with icons (lightning, chip, lightning bolt, bar chart, gear). Page 'Home' with a green link icon. Green notice: 'New patch available. Click here to apply.' with a close X. Time 09:12:56. Energy flow diagram with a house in the centre (1.700 kW) and icons for grid (0.000 kW), solar (1.700 kW), battery (green, 0.000 kW and 0.800 kW), a device at left (0.900 kW), electric vehicle and a charger or device at bottom. Label 'Energy manager' at the bottom.
http://reduxi.local. You can find the controller's IP address in your router's device list or in the Reduxi app under Reduxi devices.admin · Password: admin (factory default)Text description of this image
Screenshot of the Reduxi Configurator login page in a Chrome browser window. The address bar shows 'Not secure' and 'reduxi.local'; the address bar is marked with a cyan box and an enlarged copy of it (cyan box, text 'Not secure reduxi.local') is shown at the left, connected by a cyan line. Page background: light grey line drawing of a house with solar panels (green), a wall box, an inverter, a car and a charger. Top left: 'reduxi configurator' logo. Login box in the centre with title 'Login', a language selector (English flag, 'English'), a username field and a password field, and a dark 'Login' button.
Text description of this image
Screenshot of the Reduxi Configurator web interface after login, light theme. Top left: 'reduxi configurator' logo. Header bar: 'Home' at left, green 'Connected' status at top right. Left sidebar: expanded section 'Devices' with a list of entries, then collapsed sections 'Manager' and 'Configuration' and 'Settings'. Main area: energy flow diagram. House in the centre with ring, value 24.20 kW. Grid icon at top left, 24.20 kW (red dot on its line). Solar icon at top right, value '-'. Left icon (battery or device), 6.700 kW (green dot on its line). Right icons (battery storage and a device), values '-'. EV charger icon at bottom left, 31.00 kW. A further device icon at bottom right. Label 'Energy manager' below the house.
5 Add the AlphaESS hybrid inverter to Reduxi
Once the AlphaESS hybrid inverter is connected, register it as a new device.
5.1 Basic settings
Log in locally to the Reduxi Configurator on the controller (see Point 4) and click + Add device.
Text description of this image
Screenshot of the Reduxi Configurator sidebar. Header: reduxi Configurator logo. Section Devices (with a minus icon) lists: Iskraemeco AM550 (electricity pylon icon) and two entries with sun icons and no visible names. At the bottom is an Add device button with a plus sign, marked with a cyan rectangle.
In the first step, define the basic settings:
- Device type:
Hybrid Inverter - Type:
AlphaESS Smile Series - Name: a name of your choice, for example AlphaESS Smile G3-S5
Text description of this image
Screenshot of the Reduxi Configurator wizard step 1 'Basic settings' (step 2 is 'Communication channel', greyed). Form: Device type *: Hybrid inverter; Type *: AlphaESS Smile Series; Name *: AlphaESS Smile G3-S5 (field active with cursor, spelling underlined). Buttons: Back, Next.
Click Next to go to the communication settings.
5.2 Communication settings
This step sets up the Modbus link between the Reduxi Controller and the inverter. Choose Modbus TCP/IP or Modbus RTU, depending on the connection you use.
Modbus TCP
| Parameter | Value |
|---|---|
| Connection | TCP/IP |
| IP | IP address of the AlphaESS inverter, or use Scan for IP |
| Port | 502 |
| Modbus unit ID |
85 (default) |
Text description of this image
Screenshot of the Reduxi Configurator wizard step 2 'Communication channel' (step 1 'Basic settings' done), titled 'Communication channel and device configuration'. Fields: Connection *: TCP/IP; IP *: empty, with button 'Scan for IP' circled in red; Port *: 502. Table of found devices, columns IP address, Vendor, Already used as, each row with a '+ Select IP' button: row 1: 192.168.0.1, Advanced Digital Broadcast SA, (empty); row 2: 192.168.0.100, Alpha ESS Co., AlphaESS Smile Series, its '+ Select IP' button circled in red. Modbus unit ID *: 85. Buttons: Back, Test communication, Done.
Modbus RTU
| Parameter | Value |
|---|---|
| Connection | Local Port |
| Port | 1 |
| Baudrate | 9600 |
| Data bits | 8 |
| Stop bits | 1 |
| Parity | None |
| Modbus unit ID |
85 (default) |
Text description of this image
Screenshot of the Reduxi Configurator wizard step 2 'Communication channel' (step 1 'Basic settings' done), titled 'Communication channel and device configuration'. Fields: Connection *: Local serial port; Port *: Port 1; Baud rate *: 9600 bits/s; Data bits *: 8; Stop bits *: 1; Parity *: None; Modbus unit ID *: 85. Buttons: Back, Test communication, Done.
5.3 Test communication
Click Test communication at the bottom of the wizard. It reads the AlphaESS inverter once and saves nothing. If the test succeeds, click Done: only Done creates the device.
Text description of this image
Screenshot of the bottom button bar of a Reduxi Configurator page. Left: button 'Back'. Right: button 'Test communication' (marked with a cyan box) and dark button 'Done'.
Text description of this image
Screenshot of the Reduxi Configurator page 'Communication channel and device configuration'. Connection *: TCP/IP (dropdown). IP *: 192.168.50.243, with button 'Scan for IP'. Port *: 502, with button 'Test port'. Modbus unit ID *: 1. Buttons at the bottom: Back (left), Test communication and Done (right). The Done button is marked with a cyan box.
The test returns one of two results:
Text description of this image
Screenshot of a Test communication dialog in the Reduxi Configurator (close X at top right, dark Close button at bottom right). Green text in a white box: Successful readout from device. Battery active power: 330.0 W; Battery current: 0.9952 A; Battery export active energy: 740760.0 Wh; Battery import active energy: 765890.0 Wh; Battery max. active power: 8210.0 W; Battery max. state of charge: 100 %; Battery min. active power: -9131.0 W; Battery min. state of charge: 0.0 %; Battery state name: CHARGING null; Battery state of charge: 33.8 %; Battery state of health: 100.0 %; Battery temperature: 23.1 °C; Battery voltage: 331.6 V; Error: false null; Grid active power: 5.0 W; Grid export active energy: 1588740.0 Wh; Grid frequency: 50.01 Hz; Grid import active energy: 0.0 Wh; Grid state name: METER_ONLINE null; Inverter active power: -441.0 W; Inverter max. power: 10000.0 W; Inverter min. power: -10000.0 W; Load active power: 446.0 W; Load import active energy: 0.0 Wh; Model name: SigenStorEC100TP null; PV active power: -963.0 W; PV current: -1.99 A; PV export active energy: 0.0 Wh; PV min. active power: -10000.0 W; PV state name: CONNECTED null; PV voltage: 322.3 V; State name: RUNNING null. Additional parameters: BATTERY_CAPACITY_MAX_WH: 16120.0; BATTERY_CAPACITY_WH: 5448.56; GRID_EXPORT_POWER_ACTIVE: 0.0; GRID_IMPORT_POWER_ACTIVE: 5.0; GRID_POWER_ACTIVE_L1: 0.0; GRID_POWER_ACTIVE_L2: 5.0; GRID_POWER_ACTIVE_L3: 5.0 (partly cut off in the image); PV_POWER_ACTIVE_MAX: 0.
Text description of this image
Screenshot of a dialog titled Test communication with a close x at the top right. Message in red text: Unable to communicate with device. Dark button at the bottom right: Close.
If the test fails, check the settings and the wiring and try again.
6 Check the readings
6.1 Last measurements
Check the measured values and whether the device communicates correctly under Devices – AlphaESS Smile G3-S5 – Last measurements in the Reduxi Configurator.
Text description of this image
Screenshot of the Reduxi Configurator 'Last measurements' page of a device. Tabs: Last measurements (active), Analyze, Archive. Top right: refresh dropdown 'Without refreshing' and a refresh button. Card 'Control type': buttons Auto (light green) and Manual (dark, selected); timestamp 14. 03. 2025 12:49:13. All values below have timestamp 14. 03. 2025 12:49:01 unless noted. Card PV: PV active power -1.0 kW; PV current -1.98 A; PV voltage 327.63 V; PV export active energy 587.0 kWh; PV min. active power -10.0 kW; PV export active power limit: empty (unit kW); enumeration.PV_STATE_NAME: CONNECTED. Card Load: Load active power 0.4 kW; Load import active energy 1,109.2 kWh. Card Battery: Battery active power 0.4 kW; Battery current 1.09 A; Battery voltage 331.60 V; Battery state name CHARGING; Battery state of charge 33.80 %; Battery min. state of charge 0.00 %; Battery max. state of charge 100.00 %; Battery import active energy 765.9 kWh; Battery export active energy 740.8 kWh; Battery min. active power -9.1 kW; Battery max. active power 8.2 kW; Battery active power setpoint 1.0 kW. Card Inverter: Inverter active power -0.4 kW; Inverter max. active power 10.0 kW; Inverter min. active power -10.0 kW; State name RUNNING; Error OFF. Card Grid: Grid frequency 49.990 Hz; Grid active power 0.0 kW; Grid import active power limit: empty (kW); Grid export active power limit: empty (kW); enumeration.GRID_STATE_NAME METER_ONLINE; Grid export active energy 1,588.7 kWh; Grid import active energy 0.0 kWh. Card Other: Battery state of health 100.00 %; Battery temperature 23.10 °C; Model name SigenStorEC100TP; Communication error OFF (timestamp 12:48:56); Control type MANUAL; Mode name setpoint SELF_CONSUMPTION.
6.2 Enable control by Reduxi
For advanced control, integrate the device into the optimization modes of the Reduxi system. Under Devices – AlphaESS G3-S5 in the Reduxi Configurator, set the control type to AUTO. Only then do strategy commands affect the battery.
To achieve maximum flexibility and energy cost reduction with dynamic prices and dynamic tariffs, define a strategy as described in Strategies for Reduxi controller.
After you have added the device, you can monitor and control it via the Reduxi application.
✓ Summary
Preparation (Points 1–2): Read the manufacturer documents and prepare the cable or Wi‑Fi dongle and a laptop or tablet.
AlphaESS Smile (Point 3): Connect the inverter via LAN, Wi‑Fi dongle or Modbus RTU. Ask AlphaESS support for the latest firmware. The update activates TCP or RTU communication.
Add to Reduxi (Points 4–5): Open the Configurator and add the device with type AlphaESS Smile Series. Enter IP and port 502, or the RTU values, and Modbus unit ID 85. Run Test communication.
Go live (Point 6): Check Last measurements and set the control type to AUTO.
→ Common issues
| Issue | Solution |
|---|---|
| Test communication fails | Check the settings and the wiring. Check IP address, port 502 and Modbus unit ID 85, and that the latest firmware is installed (see Point 3). |
| Modbus TCP does not respond | The inverter needs the latest firmware, with a Wi‑Fi dongle also the dongle. Contact AlphaESS support: info@alpha-ess.com. The update activates TCP communication. |
| Modbus RTU does not respond | Check the wiring (RS 485 + on pin 5, RS 485 - on pin 4) and the RTU settings: port 1, 9600 baud, 8 data bits, 1 stop bit, no parity. The inverter needs the latest firmware. |
| IP address not found with the scan | Select the matching IP address in the list and add it with the select IP button. Otherwise enter the IP address manually. |
| Open configurator does not open or stays empty | The tunnel is not active yet. Wait about 30 seconds and check that the controller is online. |
Login with admin is rejected |
The password was changed during installation. Ask the installer. The Reduxi account password does not work here. |
reduxi.local does not load |
Your device is not in the same network as the controller. Use the IP address or the tunnel connection. |
| Communication test fails, device shows offline | Check reachability, IP address / port / unit ID, and that the protocol is enabled on the device. |
