How to connect SolarEdge inverter (with display) with Reduxi controller
Configure the SolarEdge inverter with display for Modbus TCP and add it to the Reduxi Controller.
1 Prepare the inverter
1.1 Required equipment
- Reduxi Controller
- SolarEdge inverter with display (Solar Power Plant inverter)
- SolarEdge documentation (the default password is listed there)
- Laptop or tablet with internet access to configure the device in Reduxi
2 Enable Modbus TCP on the inverter
2.1 Turn off the inverter
Turn off the inverter with the switch at the bottom of the front panel. Move the switch from 1 to 0.
Text description of this image
Photo of the lower front part of a white inverter with the printed brand name "solaredge" at the bottom. In the centre is the black rotary main switch with the printed label "ON" above it and "OFF" to its left. A red number "2." is written on the housing at the upper right. In the recess above the switch cover, a small white switch with a red mark and the digit 0 is visible, and a teal arrow points to it from the lower right. Cables enter the housing next to it.
Wait until the energy production of the inverter goes to 0 W. Then turn the main switch from ON to OFF.
Text description of this image
Photo of a white wall-mounted inverter with the printed brand name "solaredge" and the web address www.solaredge.com on the front panel. The cover has diagonal grooves. A red number "2." is written on the housing next to the lower part. In the lower section the main switch is visible with the printed labels "ON" above and "OFF" below; the switch knob is black. A teal green arrow points from the lower right at the switch. Below the unit, several dark red and black cables enter the housing from below, together with a grey corrugated conduit and a green-yellow wire. A grey vertical rail with a dark cable duct runs along the right side of the inverter.
2.2 Unscrew the 6 screws on the front cover
Text description of this image
Photo of a white wall-mounted inverter with the printed brand name "solaredge" and the web address www.solaredge.com on the front panel. Six teal numbered markers point to the six screws around the front cover: 1 at the top left corner, 2 at the left side in the upper part, 3 at the bottom left of the cover, 4 at the top right, 5 at the right side in the middle, 6 at the bottom right of the cover. The cover has diagonal grooves. A blue LCD display with white text and three small indicator labels are in the front panel. A red number "2." is written on the housing at the lower right. In the lower section the main switch has the printed label "ON" above it and the OFF label below. Below the unit, dark red and black cables, a grey corrugated conduit and a green-yellow wire enter the housing from below. A grey vertical rail with a dark cable duct is on the right side.
2.3 Enable display mode configuration and enter the password
The display unit has four small buttons. Press and hold the right button for 4 seconds.
Text description of this image
Photo of the inside of an inverter showing a green circuit board with a blue LCD display. Display text: "Please enter" (first letter partly cut off), "Password", and a row of eight asterisks. Above the display is a row of four push buttons on the board; a teal arrow points at the rightmost button of this row. Board text visible: ESC, XBEE, CARD, UNIVERSAL SOCKET; a white label with the solaredge logo and a barcode is at the top. Copper-coloured coils, green terminal blocks and white wires are around the board.
The display asks for a password. The default password is 12312312 (see the SolarEdge documentation). Enter it with the buttons: the second button is the number 1, the third button is the number 2, the fourth button is the number 3.
Text description of this image
Photo of the inside of an inverter with a blue LCD display on a green circuit board. Display text: "Please enter" (first letter partly cut off), "Password", and a row of eight asterisks. Above the display, three teal numbered markers point to three push buttons on the board: 1 (left), 2 (middle), 3 (right). Board markings near the buttons include ESC and arrow symbols, and the text "UNIVERSAL SOCKET" to the right. Green terminal blocks, white and coloured wires and a red cable are around the display.
After you enter the correct password, the display goes to the next menu automatically.
2.4 Open the Communication menu
Press the third button to go down in the menu. Press it until the sign > is at Communication. Press the fourth button to enter the Communication menu.
Text description of this image
Photo of a blue LCD display on a green circuit board inside an inverter, with a hand and finger above the board. Menu lines: "Country <SLO>", "Language <en>", "> Communication" with the cursor arrow at Communication, "Power Control". A teal marker with number 1 points to the Communication line. Status LEDs are on the right of the display. Board markings include the text XBEE and a white label with barcode. A white switch labelled 0 and 1 is visible at the bottom.
2.5 Set the TCP connection
Check the LAN configuration and enable Modbus TCP communication. Set the Modbus TCP port and define a static network IP address (recommended).
Select LAN Conf. Press the third button to go down to LAN Conf. Press the fourth button to enter it.
Text description of this image
Photo of a blue LCD display on a green circuit board inside an inverter, with a hand and finger above the board. Menu lines: "Server <L" (end partly hidden by a marker), "> LAN Conf" with the cursor arrow at LAN Conf, "RS485-1 Conf <S>", "RS485-E Conf <Dis>". A teal marker with number 1 points to the LAN Conf line. Status LEDs are on the right of the display; a white switch labelled 0 and 1 is visible below.
Select IP Config.
Text description of this image
Photo of a blue LCD display on a green circuit board inside an inverter, with a finger above the board. Menu lines: "> IP Config" with the cursor arrow at IP Config, "Set DHCP <En>", "Set IP", "Set Mask". A teal marker with number 1 points to the IP Config line. Status LEDs (green, yellow, red) are on the right of the display. Terminal blocks and wires are at the bottom.
Configure IP Config. Enter the static IP address, Mask, GW and DNS (optional) of the inverter. Press and hold the fourth button to confirm the settings.
Text description of this image
Photo of a small blue LCD display with four lines of white text, mounted on a green circuit board inside an inverter. Display text: "IP 10.49.14.201" (first characters partly cut off), "SK 255.255.255.0" (first character partly cut off), "GW 10.49.14.1", "DNS 109.239.187.4" (first character partly cut off). Around the display are the green circuit board with four push buttons at the top, green terminal blocks, small status LEDs on the right and wires at the bottom.
Press the first button to go back to the menu.
Text description of this image
Photo of a blue LCD display on a green circuit board inside an inverter, with a finger pressing near the top of the board at the left. Menu lines: "> IP Config" with the cursor arrow at IP Config, "Set DHCP <En>", "Set IP", "Set Mask". Status LEDs (green, yellow, red) are on the right of the display. Terminal blocks and wires are at the bottom.
2.6 Set the Modbus unit ID
Press the third button, go to Set Server Addr and enter the Modbus unit ID. Hold the fourth button until Applied appears, then release it.
Text description of this image
Photo of a blue LCD display on a green circuit board inside an inverter. Menu lines: "Set DNS", "Set Server Addr", "> Set Server Port" with the cursor arrow at Set Server Port, "Modbus TCP <Dis>". Above the display are four push buttons on the board with printed markings ESC and arrow symbols, a battery holder, barcode labels and the board text XBEE and UNIVERSAL SOCKET. Green terminal blocks and wires are around the display.
Press the first button to go back to the menu.
2.7 Enable Modbus TCP and set the port
Press the third button to go down in the menu. Select Modbus TCP <Dis> with the fourth button.
Text description of this image
Photo of a blue LCD display on a green circuit board inside an inverter, with a hand and finger above the board. Menu lines: "Set DNS", "Set Server Addr", "Set Server Port", "> Modbus TCP <Dis>" with the cursor arrow at Modbus TCP. A teal marker with number 1 points to the Modbus TCP line. Status LEDs are on the right of the display. A white switch labelled 0 and 1 is visible at the bottom.
Enter the port number. The default is 502. Change it with the second and third buttons, or leave 502. Hold the fourth button until the message Applied appears, then release it.
Text description of this image
Photo of a blue LCD display on a green circuit board inside an inverter. A hand with the index finger reaches over the top of the display from the left. Display text: first line "Port" with the first characters partly cut off; second line "502" with the cursor underlining the first digit. Small status LEDs (green, yellow, red) are on the right of the display. Green terminal blocks and wires are at the bottom.
Text description of this image
Photo of a blue LCD display on a green circuit board inside an inverter. Display text: first line "Port" with the first characters partly cut off; second line "502"; third line "Applied". Small status LEDs (green, yellow, red) are on the right of the display. Terminal blocks, a red component and wires are around the display; a white switch labelled 0 and 1 is visible below.
Lock the screen. Press the first button to return to the menu and lock the screen. If you do not lock it, the display locks itself after 10 to 15 minutes and the backlight turns off.
2.8 Gather the settings for the Reduxi Configurator
The inverter configuration is finished. Add the inverter to the controller with the static IP address, the port and the Modbus unit ID you entered.
3 Log in to the Reduxi web interface
You can open the Reduxi web interface in two ways:
Text description of this image
Screenshot of three Reduxi mobile app screens side by side, with cyan boxes and number badges 2 to 4. Left screen (dashboard, dark theme): menu icon at top left marked with a box and badge 2; 'reduxi' logo; tabs 'Real time data' (active) and 'Statistics'; price 5.79 € and temperature 3.2 °C; energy flow diagram with a house in the centre (-1.25 kW) and icons with values 69.0 W, 1.3 kW, 1.1 kW (red ring), -165.0 W with 97 % (red ring) and 0.0 W values at the bottom; tabs 'Power' and 'Energy'; bottom navigation: Dashboard, Diagnostics, Device control, Settings. Middle screen (side menu): 'reduxi' logo, 'Number of locations: 1233', heading 'Reduxi device management', entries '+ Add Reduxi location' and 'Reduxi devices' (marked with a box and badge 3), then 'My profile' and 'About app'. Right screen (device page): Back; picture of a black Reduxi controller with two Ethernet ports; status 'Connected'; card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'; card 'Connect to configurator': 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' with button 'Activate tunnel connection' (marked with a box and badge 4); card 'Unit details' with field 'Unit ID'.
Text description of this image
Screenshot made of two parts side by side. Left part: Reduxi mobile app screen on a dark background. Top: Back button; picture of a black Reduxi controller with two Ethernet ports and a terminal block; status 'Connected' with a Wi-Fi icon. Card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'. Card 'Connect to configurator' with a key icon: 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' and button 'Open configurator', marked with a cyan box and number badge 5. Below: card 'Unit details' with a field 'Unit ID' (value not visible). Right part: Reduxi Configurator opened in a browser, marked with a cyan frame and number badge 6. Header: back arrow, 'Tunnel connection', reload icon. Left sidebar with icons (lightning, chip, lightning bolt, bar chart, gear). Page 'Home' with a green link icon. Green notice: 'New patch available. Click here to apply.' with a close X. Time 09:12:56. Energy flow diagram with a house in the centre (1.700 kW) and icons for grid (0.000 kW), solar (1.700 kW), battery (green, 0.000 kW and 0.800 kW), a device at left (0.900 kW), electric vehicle and a charger or device at bottom. Label 'Energy manager' at the bottom.
http://reduxi.local. You can find the controller's IP address in your router's device list or in the Reduxi app under Reduxi devices.admin · Password: admin (factory default)Text description of this image
Screenshot of the Reduxi Configurator login page in a Chrome browser window. The address bar shows 'Not secure' and 'reduxi.local'; the address bar is marked with a cyan box and an enlarged copy of it (cyan box, text 'Not secure reduxi.local') is shown at the left, connected by a cyan line. Page background: light grey line drawing of a house with solar panels (green), a wall box, an inverter, a car and a charger. Top left: 'reduxi configurator' logo. Login box in the centre with title 'Login', a language selector (English flag, 'English'), a username field and a password field, and a dark 'Login' button.
Text description of this image
Screenshot of the Reduxi Configurator web interface after login, light theme. Top left: 'reduxi configurator' logo. Header bar: 'Home' at left, green 'Connected' status at top right. Left sidebar: expanded section 'Devices' with a list of entries, then collapsed sections 'Manager' and 'Configuration' and 'Settings'. Main area: energy flow diagram. House in the centre with ring, value 24.20 kW. Grid icon at top left, 24.20 kW (red dot on its line). Solar icon at top right, value '-'. Left icon (battery or device), 6.700 kW (green dot on its line). Right icons (battery storage and a device), values '-'. EV charger icon at bottom left, 31.00 kW. A further device icon at bottom right. Label 'Energy manager' below the house.
4 Add the inverter to Reduxi
Use these steps to add a new inverter or to edit an existing one.
4.1 Basic settings
Log in locally to the Reduxi Configurator via the browser (see Point 3) and click + Add device.
In the first step (basic settings), select the device type and the type of the SolarEdge inverter and enter a name of your choice. Press Next.
4.2 Communication settings
Select the communication channel and enter the settings you configured on the inverter in Point 2:
| Parameter | Value |
|---|---|
| IP | The static IP address you set on the inverter |
| Port | The Modbus TCP port you set on the inverter (default 502) |
| Modbus unit ID | The unit ID you set under Set Server Addr |
4.3 Device configuration and advanced settings
Enter the device configuration. Normally the Modbus unit ID 1 is used. Then enter and choose the advanced settings.
4.4 Test communication
Click Test communication at the bottom of the wizard. It reads the SolarEdge inverter once and saves nothing. If the test succeeds, click Done: only Done creates the device.
Text description of this image
Screenshot of the bottom button bar of a Reduxi Configurator page. Left: button 'Back'. Right: button 'Test communication' (marked with a cyan box) and dark button 'Done'.
Text description of this image
Screenshot of the Reduxi Configurator page 'Communication channel and device configuration'. Connection *: TCP/IP (dropdown). IP *: 192.168.50.243, with button 'Scan for IP'. Port *: 502, with button 'Test port'. Modbus unit ID *: 1. Buttons at the bottom: Back (left), Test communication and Done (right). The Done button is marked with a cyan box.
5 Check the readings
5.1 Last measurements
After communication is established, check the values of the inverter in the Reduxi Configurator as an additional test.
5.2 Enable control by Reduxi
To integrate the inverter into the Reduxi strategy, define a strategy as described in Strategies for Reduxi controller.
✓ Summary
Preparation (Points 1–2): Collect the equipment. Turn off the inverter, open the cover, enter the password and set LAN, static IP, Modbus unit ID and Modbus TCP port on the display.
Log in (Point 3): Log in to the Reduxi Configurator.
Add to Reduxi (Point 4): Add the inverter with the IP address, port and Modbus unit ID. Run the communication test and press Done.
Go live (Point 5): Check the readings and define a strategy.
→ Common issues
| Issue | Solution |
|---|---|
| Test communication fails | Check the IP address, port and Modbus unit ID against the values on the inverter display (see Point 2). |
| Display locked before you finish | The display locks after 10 to 15 minutes. Enter the password again (see Point 2). |
| Open configurator does not open or stays empty | The tunnel is not active yet. Wait about 30 seconds and check that the controller is online. |
Login with admin is rejected |
The password was changed during installation. Ask the installer. The Reduxi account password does not work here. |
reduxi.local does not load |
Your device is not in the same network as the controller. Use the IP address or the tunnel connection. |
| Communication test fails, device shows offline | Check reachability, IP address / port / unit ID, and that the protocol is enabled on the device. |
