How to connect AlphaESS C&I storage systems with Reduxi controller
Cut energy costs by up to 70%: Reduxi integrates AlphaESS C&I systems via Modbus TCP/IP.
Text description of this image
Logo of AlphaESS with the tagline your smart energy. At the left a stylised letter A made of grey, black, green and yellow shapes; at the right the word AlphaESS in dark grey and below it the text your smart energy.
1 Technical documentation
Manufacturer documents for the supported AlphaESS C&I systems:
- AlphaESS TB125 product page – TB125: 125 kW, 261.2 kWh, LiFePO4, IP55
- TB125 datasheet – PDF, linked from the TB125 product page
- AlphaESS H30/H50-G3 product page – H30: 30 kW, H50: 50 kW, IP55
- H30/H50-G3 datasheet – PDF, linked from the H30/H50-G3 product page
2 Required equipment
Prepare the following:
- Reduxi Controller (installed and online)
- AlphaESS C&I storage system (TB 125, G2-H30, G2-H50 or H50-G3) with the latest firmware
- Network connection between the Reduxi Controller and the AlphaESS system (Ethernet)
- IP address of the AlphaESS system (you can find it with the network scan in the Reduxi Configurator)
- Laptop or tablet with internet access to configure the device in Reduxi
3 System overview and firmware
3.1 Modbus TCP/IP connection
The picture shows the entire connection from the Reduxi Controller to the inverter.
Text description of this image
Connection diagram on a white background. Top left: black box labelled Controller with the reduxi logo. Middle left: a white router with antennas, labelled Router. Bottom left: a globe with the letters WWW. Right: a tall white cabinet with AlphaESS logo, a small control panel with indicator lights, a yellow label band near the bottom and an antenna on the top, with a smaller white box at its right side. Lines in cyan: a solid line labelled Ethernet from the Controller down to the Router; a solid line labelled Ethernet from the Router to the cabinet; a dashed line from the Router to the WWW globe.
3.2 Update the firmware
To perform the update, contact AlphaESS support by e-mail: info@alpha-ess.com
When the update is complete, continue with Point 4.
4 Activate external control on the AlphaESS system
Reduxi can only control the device if it is configured accordingly. You do this in the battery interface of the AlphaESS system (touchscreen).
4.1 Log in to the battery interface
Address of the battery interface: http://IP_AlphaESS:8085 (replace IP_AlphaESS with the IP address of the system).
| Parameter | Value |
|---|---|
| User | admin |
| Password | Alpha123! |
4.2 Set the dispatch mode
Text description of this image
Photo of a device display showing the window title 'ADA-FS Monitor - [ Channels01 ]' (left part cut off) with a German menu bar: Pflegen(M) (circled in red, marked 1.), Überwachen(G), Abfrage(Q), Ansicht(V), Sprache(L), Hilfe(H). The Pflegen(M) menu is open with entries: Starten Sie die Führungskonfiguration(G)... [Start the guided configuration]; Benutzerverwaltung(U)... [User management]; Verwaltung der Konfiguration(D) (circled in red, marked 2., highlighted, with submenu arrow) [Configuration management]; Modulverwaltung(M)... [Module management]; Optionen zur Projektkonfiguration(P)... [Project configuration options, greyed]; Optionen für die Systemkonfiguration(C)... [System configuration options, greyed]; Topologieplan importieren(E)... [Import topology plan]; Lokale Aktualisierung(L)... [Local update]. Submenu of Verwaltung der Konfiguration: Grundlegende Konfiguration(B)... (circled in red, marked 3.) [Basic configuration]; Erweiterte Parameterkonfiguration(A)... [Advanced parameter configuration]; Konfiguration der Steuerstrategie(S)... [Control strategy configuration]; Konfiguration ...leitungsbibliothek(F)... (partly hidden by a finger). Toolbar icons in the background include Einzelne-Batterie, Klimagerät, Geräteliste, Berichtsabfrage. A finger points at the submenu. In the background a power flow diagram with a yellow line and the value 3.2 kW is visible; the top of the photo shows partial letters 'ER' and 'RUN'.
Text description of this image
Photo of a computer monitor showing a German-language AlphaESS monitoring program. Tabs at the top: Grundlegende Parameterkonfiguration [Basic parameter configuration], Grundlegende Wartungskonfiguration [Basic maintenance configuration], Konfiguration externer Dispatch-Parameter [Configuration of external dispatch parameters]. The first tab is open and shows many parameter fields. A red ellipse marks the field Auswahl des Dispatch-Modus: [Selection of the dispatch mode] on the right; its dropdown shows a text (starts with Lokaler, apparently Lokaler automatischer Modus).
Text description of this image
Photo of a screen (dark background, pixelated text) of the AlphaESS interface in German. Label: Auswahl des Dispatch-Modus: [Selection of the dispatch mode]. Dropdown field: Externes Versandmodell [External dispatch model], marked by a red ellipse. Two empty input fields are at the left of the label.
Then add the device to the Reduxi Controller.
5 Log in to the Reduxi web interface
You can open the Reduxi web interface in two ways:
Text description of this image
Screenshot of three Reduxi mobile app screens side by side, with cyan boxes and number badges 2 to 4. Left screen (dashboard, dark theme): menu icon at top left marked with a box and badge 2; 'reduxi' logo; tabs 'Real time data' (active) and 'Statistics'; price 5.79 € and temperature 3.2 °C; energy flow diagram with a house in the centre (-1.25 kW) and icons with values 69.0 W, 1.3 kW, 1.1 kW (red ring), -165.0 W with 97 % (red ring) and 0.0 W values at the bottom; tabs 'Power' and 'Energy'; bottom navigation: Dashboard, Diagnostics, Device control, Settings. Middle screen (side menu): 'reduxi' logo, 'Number of locations: 1233', heading 'Reduxi device management', entries '+ Add Reduxi location' and 'Reduxi devices' (marked with a box and badge 3), then 'My profile' and 'About app'. Right screen (device page): Back; picture of a black Reduxi controller with two Ethernet ports; status 'Connected'; card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'; card 'Connect to configurator': 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' with button 'Activate tunnel connection' (marked with a box and badge 4); card 'Unit details' with field 'Unit ID'.
Text description of this image
Screenshot made of two parts side by side. Left part: Reduxi mobile app screen on a dark background. Top: Back button; picture of a black Reduxi controller with two Ethernet ports and a terminal block; status 'Connected' with a Wi-Fi icon. Card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'. Card 'Connect to configurator' with a key icon: 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' and button 'Open configurator', marked with a cyan box and number badge 5. Below: card 'Unit details' with a field 'Unit ID' (value not visible). Right part: Reduxi Configurator opened in a browser, marked with a cyan frame and number badge 6. Header: back arrow, 'Tunnel connection', reload icon. Left sidebar with icons (lightning, chip, lightning bolt, bar chart, gear). Page 'Home' with a green link icon. Green notice: 'New patch available. Click here to apply.' with a close X. Time 09:12:56. Energy flow diagram with a house in the centre (1.700 kW) and icons for grid (0.000 kW), solar (1.700 kW), battery (green, 0.000 kW and 0.800 kW), a device at left (0.900 kW), electric vehicle and a charger or device at bottom. Label 'Energy manager' at the bottom.
http://reduxi.local. You can find the controller's IP address in your router's device list or in the Reduxi app under Reduxi devices.admin · Password: admin (factory default)Text description of this image
Screenshot of the Reduxi Configurator login page in a Chrome browser window. The address bar shows 'Not secure' and 'reduxi.local'; the address bar is marked with a cyan box and an enlarged copy of it (cyan box, text 'Not secure reduxi.local') is shown at the left, connected by a cyan line. Page background: light grey line drawing of a house with solar panels (green), a wall box, an inverter, a car and a charger. Top left: 'reduxi configurator' logo. Login box in the centre with title 'Login', a language selector (English flag, 'English'), a username field and a password field, and a dark 'Login' button.
Text description of this image
Screenshot of the Reduxi Configurator web interface after login, light theme. Top left: 'reduxi configurator' logo. Header bar: 'Home' at left, green 'Connected' status at top right. Left sidebar: expanded section 'Devices' with a list of entries, then collapsed sections 'Manager' and 'Configuration' and 'Settings'. Main area: energy flow diagram. House in the centre with ring, value 24.20 kW. Grid icon at top left, 24.20 kW (red dot on its line). Solar icon at top right, value '-'. Left icon (battery or device), 6.700 kW (green dot on its line). Right icons (battery storage and a device), values '-'. EV charger icon at bottom left, 31.00 kW. A further device icon at bottom right. Label 'Energy manager' below the house.
6 Add the AlphaESS C&I system to Reduxi
Once the AlphaESS system is connected and set to external control, register it as a new device.
6.1 Basic settings
Log in locally to the Reduxi Configurator on the controller (see Point 5) and click + Add device.
Text description of this image
Screenshot of the Reduxi Configurator sidebar. Header: reduxi Configurator logo. Section Devices (with a minus icon) lists: Iskraemeco AM550 (electricity pylon icon) and two entries with sun icons and no visible names. At the bottom is an Add device button with a plus sign, marked with a cyan rectangle.
In the first step, define the basic settings. The values depend on the model:
| Model | Device type | Type | Name (example) |
|---|---|---|---|
| TB 125 | Battery |
AlphaESS TB 125 |
AlphaESS TB 125 |
| G2-H30, G2-H50, H50-G3 | Hybrid Inverter |
AlphaESS G2-H30/H50, H50-G3 |
AlphaESS G2-H30 |
Text description of this image
Screenshot of the Reduxi Configurator wizard step 1 'Basic settings' (step 2 is 'Communication channel', greyed). Form: Device type *: Battery; Type *: AlphaESS TB125; Name *: AlphaESS TB125. Buttons: Back, Next.
Text description of this image
Screenshot of the Reduxi Configurator wizard step 1 'Basic settings' (step 2 is 'Communication channel', greyed). Form: Device type *: Hybrid inverter; Type *: AlphaESS G2-H30/H50, H50-G3; Name *: AlphaESS G2-H30. Buttons: Back, Next.
Click Next to go to the communication settings.
6.2 Communication settings
This step sets up the Modbus TCP/IP link between the Reduxi Controller and the AlphaESS system. The values are the same for all models.
| Parameter | Value |
|---|---|
| Connection | TCP/IP |
| IP | IP address of the AlphaESS system, or use Scan for IP |
| Port | 502 |
| Modbus unit ID | Same as the ID of the inverter (default 1) |
Text description of this image
Screenshot of the Reduxi Configurator wizard, step 2 Communication channel (step 1 is Basic settings). Heading: Communication channel and device configuration. Fields: Connection *: TCP/IP (dropdown); IP *: empty, with a dark button Scan for IP at its right (circled in red); Port *: 502. Below the port a table of found devices with columns IP address, Vendor, Already used as, and a Select IP button per row. Row 1: 192.168.0.1; Advanced Digital Broadcast SA; Already used as: empty; button Select IP. Row 2: 192.168.0.100; Alpha ESS Co; Already used as: AlphaESS Smile Series; button Select IP (circled in red). Modbus unit ID *: 1. Buttons: Back (left), Test communication and Done (right).
6.3 Test communication
Click Test communication at the bottom of the wizard. It reads the AlphaESS once and saves nothing. If the test succeeds, click Done: only Done creates the device.
Text description of this image
Screenshot of the bottom button bar of a Reduxi Configurator page. Left: button 'Back'. Right: button 'Test communication' (marked with a cyan box) and dark button 'Done'.
Text description of this image
Screenshot of the Reduxi Configurator page 'Communication channel and device configuration'. Connection *: TCP/IP (dropdown). IP *: 192.168.50.243, with button 'Scan for IP'. Port *: 502, with button 'Test port'. Modbus unit ID *: 1. Buttons at the bottom: Back (left), Test communication and Done (right). The Done button is marked with a cyan box.
The test returns one of two results:
Text description of this image
Screenshot of a Test communication dialog in the Reduxi Configurator (close X at top right, dark Close button at bottom right). Green text in a white box: Successful readout from device. Battery active power: 330.0 W; Battery current: 0.9952 A; Battery export active energy: 740760.0 Wh; Battery import active energy: 765890.0 Wh; Battery max. active power: 8210.0 W; Battery max. state of charge: 100 %; Battery min. active power: -9131.0 W; Battery min. state of charge: 0.0 %; Battery state name: CHARGING null; Battery state of charge: 33.8 %; Battery state of health: 100.0 %; Battery temperature: 23.1 °C; Battery voltage: 331.6 V; Error: false null; Grid active power: 5.0 W; Grid export active energy: 1588740.0 Wh; Grid frequency: 50.01 Hz; Grid import active energy: 0.0 Wh; Grid state name: METER_ONLINE null; Inverter active power: -441.0 W; Inverter max. power: 10000.0 W; Inverter min. power: -10000.0 W; Load active power: 446.0 W; Load import active energy: 0.0 Wh; Model name: SigenStorEC100TP null; PV active power: -963.0 W; PV current: -1.99 A; PV export active energy: 0.0 Wh; PV min. active power: -10000.0 W; PV state name: CONNECTED null; PV voltage: 322.3 V; State name: RUNNING null. Additional parameters: BATTERY_CAPACITY_MAX_WH: 16120.0; BATTERY_CAPACITY_WH: 5448.56; GRID_EXPORT_POWER_ACTIVE: 0.0; GRID_IMPORT_POWER_ACTIVE: 5.0; GRID_POWER_ACTIVE_L1: 0.0; GRID_POWER_ACTIVE_L2: 5.0; GRID_POWER_ACTIVE_L3: 5.0 (partly cut off in the image); PV_POWER_ACTIVE_MAX: 0.
Text description of this image
Screenshot of a dialog titled Test communication with a close x at the top right. Message in red text: Unable to communicate with device. Dark button at the bottom right: Close.
If the test fails, check the settings and the wiring and try again.
7 Check the readings
7.1 Last measurements
Check the measured values and whether the device communicates correctly under Devices – AlphaESS Device – Last measurements in the Reduxi Configurator.
Text description of this image
Screenshot of the Reduxi Configurator 'Last measurements' page of a device. Tabs: Last measurements (active), Analyze, Archive. Top right: refresh dropdown 'Without refreshing' and a refresh button. Card 'Control type': buttons Auto (light green) and Manual (dark, selected); timestamp 14. 03. 2025 12:49:13. All values below have timestamp 14. 03. 2025 12:49:01 unless noted. Card PV: PV active power -1.0 kW; PV current -1.98 A; PV voltage 327.63 V; PV export active energy 587.0 kWh; PV min. active power -10.0 kW; PV export active power limit: empty (unit kW); enumeration.PV_STATE_NAME: CONNECTED. Card Load: Load active power 0.4 kW; Load import active energy 1,109.2 kWh. Card Battery: Battery active power 0.4 kW; Battery current 1.09 A; Battery voltage 331.60 V; Battery state name CHARGING; Battery state of charge 33.80 %; Battery min. state of charge 0.00 %; Battery max. state of charge 100.00 %; Battery import active energy 765.9 kWh; Battery export active energy 740.8 kWh; Battery min. active power -9.1 kW; Battery max. active power 8.2 kW; Battery active power setpoint 1.0 kW. Card Inverter: Inverter active power -0.4 kW; Inverter max. active power 10.0 kW; Inverter min. active power -10.0 kW; State name RUNNING; Error OFF. Card Grid: Grid frequency 49.990 Hz; Grid active power 0.0 kW; Grid import active power limit: empty (kW); Grid export active power limit: empty (kW); enumeration.GRID_STATE_NAME METER_ONLINE; Grid export active energy 1,588.7 kWh; Grid import active energy 0.0 kWh. Card Other: Battery state of health 100.00 %; Battery temperature 23.10 °C; Model name SigenStorEC100TP; Communication error OFF (timestamp 12:48:56); Control type MANUAL; Mode name setpoint SELF_CONSUMPTION.
7.2 Enable control by Reduxi
For advanced control, integrate the device into the optimization modes of the Reduxi system. Under Devices – AlphaESS Device in the Reduxi Configurator, set the control type to AUTO. Only then do strategy commands affect the battery.
To achieve maximum flexibility and energy cost reduction with dynamic prices and dynamic tariffs, define a strategy as described in Strategies for Reduxi controller.
After you have added the device, you can monitor and control it via the Reduxi application.
✓ Summary
Preparation (Points 1–3): Read the manufacturer documents, prepare the network connection and update the firmware via AlphaESS support. The update also activates TCP communication.
AlphaESS system (Point 4): Log in to the battery interface and set the dispatch mode to External control mode. Save.
Add to Reduxi (Points 5–6): Open the Configurator and add the device: Battery for TB 125, Hybrid Inverter for G2-H30/H50 and H50-G3. Enter IP, port 502 and Modbus unit ID (default 1). Run Test communication.
Go live (Point 7): Check Last measurements and set the control type to AUTO.
→ Common issues
| Issue | Solution |
|---|---|
| Test communication fails | Check the settings and the wiring. Check that IP address, port 502 and Modbus unit ID are correct and that the latest firmware is installed (see Point 3). |
| Modbus TCP does not respond | The device needs the latest firmware. Contact AlphaESS support: info@alpha-ess.com. The update activates TCP communication. |
| Reduxi commands have no effect on the battery | Check that the dispatch mode is External control mode (see Point 4) and that the control type in Reduxi is AUTO (see Point 7). |
| IP address not found with the scan | Select the matching IP address in the list and add it with the select IP button. Otherwise enter the IP address manually. |
| Open configurator does not open or stays empty | The tunnel is not active yet. Wait about 30 seconds and check that the controller is online. |
Login with admin is rejected |
The password was changed during installation. Ask the installer. The Reduxi account password does not work here. |
reduxi.local does not load |
Your device is not in the same network as the controller. Use the IP address or the tunnel connection. |
| Communication test fails, device shows offline | Check reachability, IP address / port / unit ID, and that the protocol is enabled on the device. |
