How to connect GARO EV chargers with Reduxi controller
Connect the GARO charger to the Reduxi Controller via OCPP over Ethernet or Wi‑Fi. The flexibility of the Reduxi system reduces costs by up to 30%.
1 Technical documentation
GARO documents for the Entity charger:
- EV charging home – GARO Entity – Brochure (PDF)
- Charging cooperative and company – GARO Entity – Brochure (PDF)
- GARO download page – Brochures and certificates
- GARO Entity PRO – Product page
2 Required equipment
You need these items:
- GARO Entity charger
- Reduxi Controller
- Smartphone with the GARO Connect app (Point 3)
- Wi‑Fi network or LAN that the charger and the Reduxi Controller both use
- Laptop or tablet with internet access to configure the device in Reduxi
3 Set up the GARO charger in the GARO Connect app
3.1 Install the GARO Connect app
Text description of this image
App icon of GARO Connect: white rounded square with the red GARO logo in the centre.
The app is available in both stores:
- Google Play Store: https://play.google.com/store/apps/details?id=se.garo.nxt&hl=en_US
- Apple App Store: https://apps.apple.com/us/app/garo-connect/id1534289157
For the first connection of the charger, watch the video tutorial First GARO Entity Connection: GARO Entity video
3.2 Log in or register in the GARO Connect app
Open the app and log in. To create a new account, tap New User, then log in.
Text description of this image
Screenshot of a mobile phone login screen of the GARO Connect app, full-height. Background: photo of a dark wooden wall with a black wall-mounted EV charger with a vertical blue light strip and a charging cable plugged in. Status bar: time 14:22, signal bars, Wi-Fi icon, battery 9. White GARO logo and the heading Welcome, then text: Log in or create a new account to get started. A light panel contains the field Email with the value tomaz.buh@reduxi.eu, and the field Password (value hidden, with a crossed-eye show/hide icon). Below: a gold button Log in; the toggle Remember me with a gold circle and white tick (on); a link Forgot your password~ (text as shown: Forgot your password with question mark). At the bottom a dark grey button New User and a white home indicator bar.
3.3 Add a new GARO charger
Follow these steps in the GARO Connect app:
Text description of this image
Screenshot of the side menu of the GARO Connect mobile app, full-height. Status bar: time 14:23, signal, Wi-Fi, battery 9. A light panel covers the right part of the screen; a dimmed grey strip on the left shows a grid icon and partly hidden background text. Top of the panel: Log out with a back-arrow icon, and a close X at the right. Menu entries in bold with divider lines: Overview; User settings; Owner (collapsed, chevron down); Installer (expanded, chevron up). Under Installer one highlighted white row with a yellow icon of a person with a hard hat: Installers menu, with a right chevron. Large empty area below. At the bottom, underlined links: Need help~ Contact our support (with question mark); Our terms of use; About the app. Then the dark GARO logo and a black home indicator bar.
Text description of this image
Screenshot of the main screen of the GARO Connect mobile app (installer view), full-height. Status bar: time 14:28, signal, Wi-Fi, battery 9. Yellow header with a location pin icon at the left, the title GARO, an icon of a person with a hard hat and a hamburger menu icon at the right. Three tabs: Charging stations (selected, gold underline), Load balancing groups, Network groups. The list area is empty except the centred text: Add a unit that should be connected to the internet first. At the bottom a dark grey button: Add new unit with a plus sign, and a black home indicator bar.
Text description of this image
Screenshot of the Add new unit screen of the GARO Connect mobile app, full-height. Status bar: time 14:28, signal, Wi-Fi, battery 9. Yellow header with a back arrow, the title Add new unit and a hard-hat person icon. Below it a picture of a white wall-mounted charger with a vertical blue light strip. Field Unit name: Home charger 1. A dropdown with the selected value GARO Entity and a down-pointing triangle (its label is not visible). Large empty area. At the bottom a gold button Add new unit and a black home indicator bar.
Text description of this image
Screenshot of the main screen of the GARO Connect mobile app (installer view) after adding a unit, full-height. Status bar: time 14:28, signal, Wi-Fi, battery 9. Yellow header with a location pin icon, the title GARO, a hard-hat person icon and a hamburger menu icon. Tabs: Charging stations (selected), Load balancing groups, Network groups. Section heading: Ungrouped or not installed units. One card with a black charger picture: Home charger 1; status Offline (grey dot); label Needs installation. Text: Are you ready with the installation~ Complete by transfer of ownership to the owner. (question mark after installation). Dark grey button Transfer location. Large empty area. At the bottom a dark grey button Add new unit with a plus sign and a black home indicator bar.
Text description of this image
Screenshot of the installation instructions screen of the GARO Connect mobile app, full-height. Status bar: time 14:28, signal, Wi-Fi, battery 9. Yellow header with a back arrow, the title Home charger 1, the text Installation progress: 0 /5 with an empty progress bar, and a hard-hat person icon. Below: a picture of a white wall-mounted charger with a blue vertical light strip; to its right two small icons, an orange crown-like icon and a green globe icon. Text: To connect to the Garo Connect app, the first unit installed in a new group must be connected to the internet via Ethernet, Wi-Fi or 4G. Note, if only one unit is to be installed at a location, a group will be created for future needs. At the bottom a gold button I have understood and a dark grey button Delete the unit, then a black home indicator bar.
Text description of this image
Screenshot of the group settings step of the GARO Connect mobile app, full-height. Status bar: time 14:29, signal, Wi-Fi, battery 8. Yellow header with a back arrow, the title Home charger 1, the text Installation progress: 0 /5 with an empty progress bar, and a hard-hat person icon. Text: Each unit that is installed belongs to a group. This applies to the installation of individual units. Field Group name: Group Garo. Field Group/Charging station max current (A): 16. Hint below: (6 - 6000 A). Large empty area. At the bottom a gold button Next and a black home indicator bar.
Text description of this image
Screenshot of the internet access selection screen of the GARO Connect mobile app, full-height. Status bar: time 14:29, signal, Wi-Fi, battery 8. Yellow header with a back arrow, the title Home charger 1, the text Installation progress: 0 /5 with an empty progress bar, and a hard-hat person icon. Text: Select how to access internet. Three selectable cards, each with a drawing of a charger connected to a globe: Ethernet (cable symbol, white card, not selected); Wi-Fi (Wi-Fi waves and a WiFi badge on the globe; light green card with a grey border, selected); Modem (waves and a 4G badge on the globe, white card, not selected). At the bottom a gold button Save and continue installation and a black home indicator bar.
Text description of this image
Screenshot of the DLM group preview step of the GARO Connect mobile app, full-height. Status bar: time 14:29, signal, Wi-Fi, battery 8. Yellow header with a back arrow, the title Home charger 1, the text Installation progress: 0 /5 with an empty progress bar, and a hard-hat person icon. Heading: DLM group preview. Below it a tree line to the group name Group Garo. Under the group a white card with a red left edge, an outline drawing of a charger, the text Home charger 1 and an orange crown icon at the right. Large empty area. At the bottom a gold button OK, continue installation, a dark grey button Not OK, redo grouping, and a black home indicator bar.
Text description of this image
Screenshot of a phone app screen titled "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:29, signal bars, Wi-Fi icon, battery showing 8. Yellow header with a back arrow on the left, the title "Home charger 1" and a settings (gear) icon on the right. Below, a white charger unit is shown with a blue vertical light strip. Next to it: "Not connected" in red, "Wifi", an orange icon and a grey globe icon. "Progress" with a progress bar about one fifth filled in green and the value "1 /5". Button: "Continue installation". Step list: "Grouping" with "Completed" and a green tick; "Grid connection" with "Waiting for installation" and a right arrow; "Installation bracket ID" with "Waiting for installation" (greyed out); a message box with an exclamation icon: "Power on the unit and wait for the green light"; "Communication settings" with "Waiting for installation" (greyed out); "Declare installed" with "Waiting for installation" (greyed out). A round gold help button with a book and question mark icon is at the bottom right.
Text description of this image
Screenshot of a phone app screen titled "Grid connection" with subtitle "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:29, signal bars, Wi-Fi icon, battery showing 8. Yellow header with a back arrow and a settings (gear) icon. Card 1: "Installation bracket max current (A)" with an info icon; value 16. Card 2: "Number of enabled phases for bracket" with a three-way selector: 1-phase, 2-phase, 3-phase; 3-phase is selected (gold). "Phase rotation for bracket": 0.RST. Section "TN400V phase rotation" with a box "Bracket" and a header row of terminals PE, L1, L2, L3, N. Below, the selectable rotation options as coloured rows: the selected row (blue outline) PE (green), L1 (gold), L2 (dark grey), L3 (grey), N (blue); next row PE, L2, L3, L1, N (lighter); next row PE, L3, L1, L2, N (lighter, partly cut). Buttons at the bottom: "Restore default"; "Installation manual" with a book and question mark icon; gold button "Grid connection tested OK, confirm settings and proceed".
Text description of this image
Screenshot of a phone app screen titled "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:30, signal bars, Wi-Fi icon, battery showing 8. Yellow header with a back arrow, the title "Home charger 1" and a settings (gear) icon. A white charger unit with a blue vertical light strip; next to it "Not connected" in red, "Wifi", an orange icon and a grey globe icon. "Progress" with a green progress bar about two fifths filled and the value "2 /5". Button: "Continue installation". Step list: "Grouping" with "Completed" and a green tick; "Grid connection" with "Completed" and a green tick; "Installation bracket ID" with "Waiting for installation" and a gold right arrow (the active step); a message box with an exclamation icon: "Power on the unit and wait for the green light"; "Communication settings" with "Waiting for installation" (greyed out); "Declare installed" with "Waiting for installation" (greyed out). A round gold help button with a book and question mark icon is at the bottom right.
Text description of this image
Screenshot of a phone app screen titled "Installation bracket ID" with subtitle "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:30, signal bars, Wi-Fi icon, battery showing 8. Yellow header with a back arrow and a settings (gear) icon. The main part is an illustration of the back of a dark charger bracket with a green five-way terminal block with a printed earth symbol, L1, L2, L3 and N. Five wires (green, brown, black, grey, blue) are connected to the top of the terminal block. A green QR code is shown on the bracket, with a green beam pointing to a hand-held phone whose screen shows the red logo "GARO" and "Connect APP" with scan corner marks. The illustration continues with a white hand holding the phone next to the open bracket with a cable gland and cable. Below the illustration: the text "Scan the QR code from the installed bracket"; gold button "Read QR code on bracket" with a scan icon; grey (inactive) button "Complete".
Text description of this image
Screenshot of a phone app screen titled "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:30, signal bars, Wi-Fi icon, battery showing 7. Yellow header with a back arrow, the title "Home charger 1" and a settings (gear) icon. A white charger unit with a blue vertical light strip; next to it "Not connected" in red, "Wifi", an orange icon and a grey globe icon. "Progress" with a green progress bar about three fifths filled and the value "3 /5". Button: "Continue installation". Step list: "Grouping", "Grid connection" and "Installation bracket ID", each with "Completed" and a green tick; a message box with an exclamation icon: "Power on the unit and wait for the green light"; "Communication settings" with "Waiting for installation" and a gold right arrow (the active step); "Declare installed" with "Waiting for installation" (greyed out). A round gold help button with a book and question mark icon is at the bottom right.
Text description of this image
Screenshot of a phone app screen "Communication settings" with subtitle "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:31, signal bars, Wi-Fi icon, battery showing 7. Yellow header with a back arrow and an installer (person with hard hat) icon. Step indicator row of five circles numbered 1 to 5; step 1 is highlighted gold, steps 2 to 5 are white. Below, a photo-style image of a dark charging unit mounted on a wall: the front cover is open on the left showing a row of white switch levers with a blue curved arrow pointing upward, and a display on the right; a vertical light strip on the front glows solid green. Text under the image: "Turn on the charging unit and wait until the box lights up with a solid green light. This can take up to 90 seconds." and "Then click Next and select Connect to pair your mobile device with the charger." Gold button at the bottom right: "Next".
Text description of this image
Screenshot of a phone app screen "Communication settings" with subtitle "Home charger 1" (GARO Connect app per the existing alt text), dimmed by a modal dialog. Phone status bar: time 14:32, signal bars, Wi-Fi icon, battery showing 7. Header has a back arrow and an installer (person with hard hat) icon. Step indicator row of five circles: steps 1, 2 and 3 are green with ticks, step 4 is highlighted gold, step 5 is grey. Behind the dialog, a heading "Set up internet connection for charging station" and a partly hidden section starting with "U". Centre dialog (white card) with a line icon of a mobile phone, Wi-Fi waves and a charging station, and the text "Verifying the direct Wi-Fi connection between your mobile device and charging station.". Dialog button: "Cancel". Dimmed at the bottom behind the dialog: link "Download EVSE log files", buttons "Previous" (outlined) and "Next" (filled, greyed).
Text description of this image
Screenshot of a phone app screen "Communication settings" with subtitle "Home charger 1" (GARO Connect app per the existing alt text), dimmed by an overlay. Phone status bar: time 14:32 with a location arrow, signal bars, Wi-Fi icon, battery showing 6. Header has a back arrow and an installer (person with hard hat) icon. Step indicator row: steps 1, 2 and 3 are green with ticks, step 4 is highlighted gold, step 5 is grey. Behind the overlay: heading "Set up internet connection for charging station" and a dialog card with a line icon of a phone, Wi-Fi waves and a charging station. On top, an iOS system prompt: "GARO Connect" Wants to Join Wi-Fi Network "GaroCU-4C3B6C012EE0"? (the network name is split across two bands, the last part visible as GaroCU-4C3B6C012EE0). Prompt buttons: "Cancel" (left) and "Join" (right, bold blue). Dimmed at the bottom: link "Download EVSE log files", buttons "Previous" (outlined) and "Next" (greyed).
Text description of this image
Screenshot of a phone app screen "Communication settings" with subtitle "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:38 with a location arrow, signal bars, 5G, battery showing 6. Header has a back arrow and an installer (person with hard hat) icon. Step indicator row: steps 1, 2 and 3 are green with ticks, step 4 is highlighted gold, step 5 is white. Heading: "Set up internet connection for charging station". Dropdown: Wi-Fi (selected, with a down arrow). Sub-heading: "Use 2,4 GHz Wi-Fi for internet connection". Line illustration: a phone, green Wi-Fi waves, the charging station, grey Wi-Fi waves, and a globe with a Wi-Fi sign. Grey button: "Refresh" (inactive). Below it, in a white card, two empty light-blue placeholder bars (list of networks not shown or still loading). Bottom buttons: "Previous" (outlined) and "Next" (grey, inactive).
Text description of this image
Screenshot of a phone app screen "Communication settings" with subtitle "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:38, signal bars, Wi-Fi icon, battery showing 6. Header has a back arrow and an installer icon. Step indicator row: steps 1, 2 and 3 are green with ticks, step 4 gold, step 5 white. Heading: "Set up internet connection for charging station". Dropdown: Wi-Fi (selected). Sub-heading: "Use 2,4 GHz Wi-Fi for internet connection". Line illustration of a phone, green Wi-Fi waves, the charging station, grey waves and a globe with a Wi-Fi sign. Dark button: "Refresh". List of found Wi-Fi networks, each in an outlined row with signal strength and a green Wi-Fi icon: "Ar" followed by a hidden part, -42 dBm; "Gue" followed by a hidden part, -43 dBm; "ami" followed by a hidden part, -43 dBm (names covered by white boxes with black outlines; the list continues below, cut off). Bottom buttons: "Previous" (outlined) and "Next" (grey, inactive).
Text description of this image
Screenshot of a phone app screen "Communication settings" with subtitle "Home charger 1" (GARO Connect app per the existing alt text), dimmed by a modal dialog. Phone status bar: time 14:39, signal bars, Wi-Fi icon, battery showing 5. Header has a back arrow and an installer icon. Step indicator row: steps 1, 2 and 3 are green with ticks, step 4 gold, step 5 grey. Dialog (white card) with the heading: The Wi-Fi network "am[part of the name hidden by a white box with a black outline] may require password. Field label "Password" with an empty input line and a show/hide (crossed eye) icon. Gold button "Connect" and dark button "Cancel". Dimmed behind the dialog is a list of Wi-Fi networks, each with signal strength and a green Wi-Fi icon: "Arhea" -42 dBm; "GuestDr" -43 dBm; "amibit" -43 dBm (the list continues below, cut off). Bottom buttons dimmed: "Previous" (outlined) and "Next" (greyed).
Text description of this image
Screenshot of a phone app screen "Communication settings" with subtitle "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:39, signal bars, Wi-Fi icon, battery showing 5. Header has a back arrow and an installer icon. Step indicator row: steps 1 to 4 are green with ticks, step 5 is highlighted gold. Heading: "Close direct Wi-Fi connection to charging station's access point and connect your mobile device to internet." Line illustration: a phone and the charging station joined by a dotted line with a red cross between them, and green Wi-Fi waves from the charging station to a globe with a Wi-Fi sign. Text: "Wait until selected network is confirmed by charging station...". Gold button: "Close connection". Bottom buttons: "Previous" (outlined, greyed text) and "Complete" (grey, inactive).
Text description of this image
Screenshot of a phone app screen titled "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:40, signal bars, Wi-Fi icon, battery showing 5. Yellow header with a back arrow and a settings (gear) icon. Tabs: "Installation" (selected, gold underline), "Status", "Monitoring". A white charger unit with a blue vertical light strip; next to it "Online" in green, "Wifi", an orange crown icon and a green globe icon. "Progress" with a green progress bar about four fifths filled and the value "4 /5". Button: "Continue installation". Step list: "Grouping", "Grid connection", "Installation bracket ID", each with "Completed" and a green tick; a message box with an exclamation icon: "Power on the unit and wait for the green light"; "Communication settings" with "Completed" and a green tick; "Declare installed" with "Waiting for installation" and a gold right arrow (the active step). A round gold help button with a book and question mark icon is at the bottom right.
Text description of this image
Screenshot of a phone app screen titled "Declare installed" with subtitle "Home charger 1" (GARO Connect app per the existing alt text). Phone status bar: time 14:40, signal bars, Wi-Fi icon, battery showing 5. Yellow header with a back arrow and an installer (person with hard hat) icon. Status at the top right: green dot with "Available". Two cards with grey numbered circles: 1 "Test and verify function"; 2 "Declare as installed". Toggle row: "Unit tested OK, declare as installed" with the switch on (green). Dark button: "Installation manual" with a book and question mark icon. Gold button: "Next".
3.4 Factory reset
A factory reset is required when you move the charger or connect it to a different network.
- Press and hold the test button for 20 seconds.
- Configure the GARO charger again afterwards (Point 3.3).
Text description of this image
Screenshot of a phone browser (Safari) showing a PDF page of the GARO charger manual. Phone status bar: time 14:37, signal bars, Wi-Fi icon, battery showing 6. Address bar: "...ical-documentation.garo-next-gen.com" (start of the address cut off) with a lock and reload icon. Page indicator "89 of 102", footer "Version: 1.3.2", page number 89. Page header "Maintenance". Page content: "6 MAINTENANCE"; "6.1 TO CLEAN THE CHARGING STATION": use a damp cloth to clean the exterior; CAUTION: do not use running water or a hard brush to clean the charging station, it can cause damage. "6.2 TO DO A VISUAL CHECK OF THE CHARGING STATION": 1. Make sure that the charging station is clean. 2. Do a visual check of the charging station, Type 2 connector and the power cables, check for damages such as cracks or deformation. WARNING: do not use a damaged charging station; turn off the electric power and disable the charging station in the GARO Connect app; contact an authorized service center. "6.3 TO DO A FACTORY RESET": CAUTION: the GARO support organization should approve a factory reset; it should only be done as a last resort in case of errors, such as lost contact to the network or the GARO Connect app. Steps: 1. Stop charging and disconnect any EV. 2. Remove the front cover of the charging unit (reference to 4.12.16, page 43). 3. Do a long press, approximately 20 seconds, on the test button (T) with the designation T, using a pen or similar; the circuit breaker will trip and the indication turns into a blinking red light. 4. After the light goes off, release the button and the circuit breaker can be closed. 5. Wait for the device to restart and the light to turn green. "6.4 TO DO AN EARTH FAULT TEST": note to do an earth fault test 2 times/year; steps 1 and 2 (short press, max. 1 second, on the test button T); note that the indication light becomes blinking red and the circuit breaker trips. Drawing on the right: the open charging unit with a vertical light strip, a row of circuit breakers, a display, and the test button labelled T with a callout line to a circle with T; an inset shows a pen pointing downward. Safari bottom toolbar with back, forward, share, bookmarks and tabs icons.
4 Connect the charger and the Reduxi Controller to the same network
The Reduxi Controller and the GARO charger must be on the same network (LAN or WLAN) to communicate. Use the same network that you selected for the GARO charger in Point 3.3 (Wi‑Fi network selection).
When this is the case, continue with the OCPP configuration.
Text description of this image
Screenshot of a phone app screen "Communication settings" with subtitle "Home charger 1" (GARO Connect app per the existing alt text), dimmed by a modal dialog. Phone status bar: time 14:39, signal bars, Wi-Fi icon, battery showing 5. Header has a back arrow and an installer icon. Step indicator row: steps 1, 2 and 3 are green with ticks, step 4 gold, step 5 grey. Dialog (white card) with the heading: The Wi-Fi network "am[part of the name hidden by a white box with a black outline] may require password. Field label "Password" with an empty input line and a show/hide (crossed eye) icon. Gold button "Connect" and dark button "Cancel". Dimmed behind the dialog is a list of Wi-Fi networks, each with signal strength and a green Wi-Fi icon: "Arhea" -42 dBm; "GuestDr" -43 dBm; "amibit" -43 dBm (the list continues below, cut off). Bottom buttons dimmed: "Previous" (outlined) and "Next" (greyed).
5 Log in to the Reduxi web interface
You can open the Reduxi web interface in two ways:
Text description of this image
Screenshot of three Reduxi mobile app screens side by side, with cyan boxes and number badges 2 to 4. Left screen (dashboard, dark theme): menu icon at top left marked with a box and badge 2; 'reduxi' logo; tabs 'Real time data' (active) and 'Statistics'; price 5.79 € and temperature 3.2 °C; energy flow diagram with a house in the centre (-1.25 kW) and icons with values 69.0 W, 1.3 kW, 1.1 kW (red ring), -165.0 W with 97 % (red ring) and 0.0 W values at the bottom; tabs 'Power' and 'Energy'; bottom navigation: Dashboard, Diagnostics, Device control, Settings. Middle screen (side menu): 'reduxi' logo, 'Number of locations: 1233', heading 'Reduxi device management', entries '+ Add Reduxi location' and 'Reduxi devices' (marked with a box and badge 3), then 'My profile' and 'About app'. Right screen (device page): Back; picture of a black Reduxi controller with two Ethernet ports; status 'Connected'; card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'; card 'Connect to configurator': 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' with button 'Activate tunnel connection' (marked with a box and badge 4); card 'Unit details' with field 'Unit ID'.
Text description of this image
Screenshot made of two parts side by side. Left part: Reduxi mobile app screen on a dark background. Top: Back button; picture of a black Reduxi controller with two Ethernet ports and a terminal block; status 'Connected' with a Wi-Fi icon. Card 'Update available': 'New update is available for your Reduxi device.' with button 'Download and install update'. Card 'Connect to configurator' with a key icon: 'Tunnel connection enables remote access to your Reduxi configurator, without need to be connected to the same local network.' and button 'Open configurator', marked with a cyan box and number badge 5. Below: card 'Unit details' with a field 'Unit ID' (value not visible). Right part: Reduxi Configurator opened in a browser, marked with a cyan frame and number badge 6. Header: back arrow, 'Tunnel connection', reload icon. Left sidebar with icons (lightning, chip, lightning bolt, bar chart, gear). Page 'Home' with a green link icon. Green notice: 'New patch available. Click here to apply.' with a close X. Time 09:12:56. Energy flow diagram with a house in the centre (1.700 kW) and icons for grid (0.000 kW), solar (1.700 kW), battery (green, 0.000 kW and 0.800 kW), a device at left (0.900 kW), electric vehicle and a charger or device at bottom. Label 'Energy manager' at the bottom.
http://reduxi.local. You can find the controller's IP address in your router's device list or in the Reduxi app under Reduxi devices.admin · Password: admin (factory default)Text description of this image
Screenshot of the Reduxi Configurator login page in a Chrome browser window. The address bar shows 'Not secure' and 'reduxi.local'; the address bar is marked with a cyan box and an enlarged copy of it (cyan box, text 'Not secure reduxi.local') is shown at the left, connected by a cyan line. Page background: light grey line drawing of a house with solar panels (green), a wall box, an inverter, a car and a charger. Top left: 'reduxi configurator' logo. Login box in the centre with title 'Login', a language selector (English flag, 'English'), a username field and a password field, and a dark 'Login' button.
Text description of this image
Screenshot of the Reduxi Configurator web interface after login, light theme. Top left: 'reduxi configurator' logo. Header bar: 'Home' at left, green 'Connected' status at top right. Left sidebar: expanded section 'Devices' with a list of entries, then collapsed sections 'Manager' and 'Configuration' and 'Settings'. Main area: energy flow diagram. House in the centre with ring, value 24.20 kW. Grid icon at top left, 24.20 kW (red dot on its line). Solar icon at top right, value '-'. Left icon (battery or device), 6.700 kW (green dot on its line). Right icons (battery storage and a device), values '-'. EV charger icon at bottom left, 31.00 kW. A further device icon at bottom right. Label 'Energy manager' below the house.
6 Add the GARO charger to Reduxi
Use these steps to add a new GARO charger or to edit an existing one. The charger communicates with the Reduxi Controller via OCPP.
6.1 Basic settings
Log in locally to the Reduxi Configurator on the controller (see Point 5) and click + Add device.
Text description of this image
Screenshot of the left sidebar of the Reduxi Configurator. Top: reduxi logo with the text CONFIGURATOR. Collapsed sections: Devices (plus icon) and Strategies (plus icon). Below, two buttons side by side: Add device (plus icon, marked with a blue highlight box) and Add strategy (plus icon). Below them two entries: Settings and Profile. The area to the right of the sidebar is empty white.
In the first step, select the basic parameters:
- Device type:
EV Charger - Protocol:
OCPP 1.6 - JSON - Name: a name of your choice, for example GARO Entity
Text description of this image
Screenshot of the Reduxi Configurator add-device wizard, step 1 of 3. Progress bar with three steps: 1 Basic settings (active, black circle), 2 Communication channel (grey), 3 Advanced settings (grey). Heading: Basic settings. Fields: Device type * : empty dropdown; Type * : empty dropdown; Name * : empty text field. Buttons: Back (bottom left), Next (bottom right, dark).
6.2 Communication settings
The second step sets the communication channel and tests the OCPP communication. Enter these values:
| Parameter | Value |
|---|---|
| Device identifier | The identifier you obtained from the GARO charger |
| OCPP server URL | Generated by the Reduxi Controller. Copy it from the communication channel. Example: ws://192.168.1.121/ocpp/1.6/json/
|
Text description of this image
Screenshot of the Reduxi Configurator section "Device configuration". Fields: Device identifier *: GaroCS-43A4DB2076B80; Connector *: 1; Charger type *: AC; Energy counter: Default; Allocate power to EVSE when EV is not connected to EVSE: Default; Per phase max. current *: Manual override; Per phase max. current manual override: 32 (hint: In effect when manual override is selected); Forward communication to backend OCPP server: wss://csms.garo-next-gen.com:443; Forward measurements to backend OCPP server once every: empty dropdown; Allow new charging session: Always; Controller OCPP JSON 1.6 URL: ws://192.168.1.121/ocpp/1.6/json (read-only field with a copy icon at its right).
6.3 Enter the OCPP server URL in the GARO charger
Paste the JSON URL from the Reduxi Controller into the GARO charger to enable the OCPP connection.
- Open Configuration on the GARO charger, then OCPP Settings.
- Scroll down to GaroCsmsURL and paste the URL.
Text description of this image
Screenshot of a phone app screen titled "Configuration" with subtitle "Home charger 1", section "OCPP settings" (GARO Connect app per the existing alt text). Phone status bar: time 14:46, signal bars, Wi-Fi icon, battery showing 5 with a charging bolt. Yellow header with a back arrow and an installer (person with hard hat) icon. Parameter cards, each with an info icon: "AllowOfflineTxForUnknownId": round checkbox not ticked; "AuthorizationCacheEnabled": round checkbox ticked (grey circle with white tick); "AuthorizationKey": empty text field; "AuthorizeRemoteTxRequests": round checkbox not ticked; "ConnectionTimeOut": value 40; "GaroClientCert": heading only, rest cut off by the buttons. Buttons at the bottom: "Reboot unit" (dark), "Restore default" (dark), "Update changes" (grey, inactive). A scrollbar is visible on the right.
Text description of this image
Screenshot of a phone app screen titled "Configuration" with subtitle "Home charger 1" (GARO Connect app, parameter list of the charger). Phone status bar: time 10:11, signal bars, Wi-Fi icon, battery showing 66. Yellow header with a back arrow and an installer (person with hard hat) icon. A collapsible card with an info icon, the text "Offline" and a down chevron. Parameter cards, each with an info icon: "ConnectionTimeOut" value 40; "GaroClientCert" empty; "GaroCsmsUrl" value ws://192.168.1.121/ocpp/1.6/json, with a circular reset arrow icon on the right, and the line "Unit updated at: 2024-09-25 15:04"; "GaroFinishingTimeOut" value 0; "GaroVerifyCertificates" (value not visible, cut off by the button area). Buttons at the bottom: "Reboot unit" (dark), "Restore default" (dark), "Update changes" (grey, inactive). A scrollbar is visible on the right.
6.4 Test communication
Click Test communication at the bottom right, below the communication channel fields. It checks the OCPP communication.
Text description of this image
Screenshot of the Reduxi Configurator add-device wizard, step 2 of 3 (Communication channel). Progress bar: 1 Basic settings (black), 2 Communication channel (black, active), 3 Advanced settings (grey). Heading: Communication channel and device configuration. Fields: Device identifier *: my_station_ID1 (text field being edited, green outline); Connector *: 1; Charger type *: AC; Energy counter: Default; Allocate power to EVSE when EV is not connected to EVSE: Default; Per phase max. current *: Manual override; Per phase max. current manual override: 32 (hint below, small); Forward communication to backend OCPP server: empty; Allow new charging session: Always; Controller OCPP JSON 1.6 URL: ws:// address followed by /ocpp/1.6/json. Buttons at the bottom: Back (left), Test communication (marked with a blue box) and Next (right).
The test returns one of three results:
- Success: communication works correctly.
- Error 1: the controller cannot communicate with the device. The device identifier is not set or is incorrect.
- Error 2: no OCPP 1.6 compatible device is available.
Text description of this image
Screenshot of a dialog titled "Test communication" with a close button (x) at top right, over a dimmed form. Green text: "Successful readout from device". Values: Current L1: 0.0 A; Current L2: 0.0 A; Current L3: 0.0 A; Import active power: 0.0 W; Max. active power: 22080.0 W; Max. current per phase: 32.0 A; Min. active power: 0 W; State name: AVAILABLE. Button at bottom right: Close.
Text description of this image
Screenshot of a dialog titled "Test communication" with a close button (x) at top right, over a dimmed form. First box: "Unable to communicate with device." Second box: "Number of devices found on OCPP - JSON 1.6: 1" and "Device identifier: GaroCS-43A4DB2076B80". Button at bottom right: Close. Behind the dialog the dimmed form shows the labels "Energy counter" at the top and "Forward communication to backend OCPP server" at the bottom.
Text description of this image
Screenshot of a dialog titled "Test communication" with a close button (x) at top right, shown over a dimmed page. First box: "Unable to communicate with device." Second box: "Number of devices found on OCPP - JSON 1.6: 0". Button at bottom right: Close.
6.5 Advanced settings
Configure the advanced settings and select the parameters as shown in the image. The settings may vary with the needs of the location.
Text description of this image
Screenshot of the Reduxi Configurator add-device wizard, step 3 of 3 (Advanced settings). Progress bar with three black circles 1 Basic settings, 2 Communication channel, 3 Advanced settings (active). Heading: Advanced settings. Eight yes/no questions, each with a toggle that is off and a small default hint at the right: data-saving interval (Default: 1 min); reading delay (Default: 1000 ms); writing delay (Default: 1000 ms); power generation limits and capabilities; power consumption limits and capabilities; limit communication with the device to read-only (Default: No); invert direction for energy import and export (Default: No); exclude device from summary (Default: No). Bottom row of three dropdowns about L1, L2 and L3 connected to main feed (values small). Buttons: Back (left) and a dark button at the bottom right (label small, reads Done).
When you are done, click Finish on the right side of the screen.
7 Check the readings
7.1 Last measurements
To check the device readings, go to Device – Last Measurement in the Reduxi Configurator.
Text description of this image
Screenshot of the Last measurements view of a device in the Reduxi Configurator. Tabs: Last measurements (active), Analyze, Archive. Top right: refresh interval dropdown Each second and a refresh button. Card Control type: buttons Auto (selected, teal), Manual, Off, Boost; timestamp 10. 05. 2024 07:28:27. Card Current: Per phase current setpoint 6.00 A; Max. current per phase 32.00 A; Current L3 0.00 A; Current L2 0.00 A; Current L1 0.00 A (timestamps 10. 05. 2024 07:28:45 to 07:28:46). Card Power: Min. active power 0.0 kW; Active power 0.0 kW; Import active power 0.0 kW. Card Energy: Import active energy - session 4.4 kWh; Import active energy 1,848.8 kWh. Card Other: Control type AUTO; State name AVAILABLE; Communication error OFF (timestamp 07:28:42).
7.2 Monitor and control
When the device is added in the Reduxi Configurator, you can monitor it in the web app Reduxi Cloud.
To reduce energy costs with dynamic prices and dynamic tariffs, define a strategy as described in Strategies for Reduxi controller.
✓ Summary
Preparation (Points 1–2): Collect the GARO documents and the equipment: charger, Reduxi Controller, smartphone and a laptop or tablet.
GARO Entity (Points 3–4): Install the GARO Connect app, add the Entity charger and connect it to the same network as the Reduxi Controller.
Add to Reduxi (Points 5–6): Log in to the Reduxi Configurator, add an EV Charger with OCPP 1.6 - JSON, paste the OCPP server URL into the charger and test the communication.
Go live (Point 7): Check the readings under Device – Last Measurement, monitor in Reduxi Cloud and define a strategy.
→ Common issues
| Issue | Solution |
|---|---|
| Test shows "Unable to communicate with device" (Error 1) | The device identifier is not set or is incorrect. Enter the identifier obtained from the GARO charger (Point 6.2). |
| Test shows that no OCPP 1.6 device was found (Error 2) | Check that the charger and the Reduxi Controller are on the same network (Point 4) and that the OCPP server URL is entered in GaroCsmsURL (Point 6.3). |
| The charger is moved or must connect to another network | Do a factory reset: hold the test button for 20 seconds. Then configure the charger again (Point 3.3). |
| Open configurator does not open or stays empty | The tunnel is not active yet. Wait about 30 seconds and check that the controller is online. |
Login with admin is rejected |
The password was changed during installation. Ask the installer. The Reduxi account password does not work here. |
reduxi.local does not load |
Your device is not in the same network as the controller. Use the IP address or the tunnel connection. |
| Communication test fails, device shows offline | Check reachability, IP address / port / unit ID, and that the protocol is enabled on the device. |
