Screenshot of a phone app screen "Upgrade charger" (DAZE app per the existing alt text). Phone status bar: time 23:54 with a location arrow, Dynamic Island with a green dot, signal bars, LTE, battery showing 5. Blue back arrow top left. Heading: "Upgrade charger". Question: "Do you want to enable updates to your charger?". Text: "If you select yes, if the charger is connected to an internet network the updates will be done automatically, otherwise, if the charger is not connected to the internet network, you will be able to update it manually via Bluetooth." and "If you select no, you will not be able to perform any kind of updates except the mandatory ones. Select no only in case of charger management via third-party OCPP back-end." Two radio options: "Yes, I want all the updates" (selected, filled radio button); "No, only mandatory updates" with the line "Mandatory choice for third-party OCPP backend" (not selected). Blue full-width button at the bottom: "Next".

Screenshot of a phone app screen "Upgrade charger" (DAZE app per the existing alt text) dimmed by a grey overlay, with a modal alert on top. Status bar: time 23:54 with a location arrow, signal bars, LTE, battery showing 5 with a red edge. Back arrow at the top left. Heading: "Upgrade charger". Question: "Do you want to enable updates to your charger?". Text: "If you select yes, if the charger is connected to an internet network the updates will be done automatically, otherwise, if the charger is not connected to the internet network, you will be able to update it manually via Bluetooth." Second paragraph: "If you select no, you will not be able to perform any kind of updates except the mandatory ones. Select no only in case of charger management via third-party OCPP back-end." Two radio options partly hidden behind the alert: the first begins "Yes, I w" (rest hidden) and is selected (filled dot); the second begins "No, on" with a smaller line starting "Mandat" (rest hidden) and is not selected (empty circle). Alert dialog (light grey rounded box): title "Warning", text "The next step requires connecting the phone to the charger via Bluetooth.", and a blue button "Ok". At the bottom a dimmed dark button "Next" and a home indicator bar. The image is 1179 px wide and the right part of the screenshot canvas next to the phone screen is white.

Screenshot of a phone app screen (DAZE app per the existing alt text) with a photo background of a grey and black EV charger. Status bar: time 23:54 with a location arrow, signal bars, LTE, battery showing 5 with a red edge. The charger photo has a black front panel with a blue light strip at the top, a small white seven-segment style display, a circular wave symbol and small car, plug and other icons; a thick black charging cable loops around the charger and ends in a black plug on the right. Over the photo is a light lavender rounded panel with a blue smiley icon and the blue text "Bluetooth connection in progress". No buttons are visible. A black rounded home indicator bar at the very bottom.

Screenshot of a phone app screen "Power Management" (DAZE app per the existing alt text). Status bar: time 23:55 with a location arrow, signal bars, LTE, battery showing 5 with a red edge. Blue back arrow at the top left. Heading: "Power Management". Grey subtitle: "Choose how to manage the power of your charger". Four option cards in a 2 by 2 grid, each with a black circle containing a white exclamation mark in the top right corner. Top left card, selected (blue outline and blue text), with a blue house icon: "One charger with Dynamic Power Manager". Top right card, grey: pushpin icon, "One or more fixed power charging stations". Bottom left card, grey: icon of connected nodes, "Multiple chargers in Power Sharing". Bottom right card, grey: cloud-style icon with an upward arrow, "Multiple chargers with an external master". Blue full-width rounded button near the bottom: "Next". Black home indicator bar at the very bottom.

Screenshot of a phone app screen "Power Management" (DAZE app per the existing alt text). Phone status bar: time 23:55 with a location arrow, Dynamic Island with a green dot, signal bars, LTE, battery showing 5. Blue back arrow at the top left. Heading: "Power Management". Sub-text: "Choose how to manage the power of your charger". Four option tiles in a 2 by 2 grid, each with a black round exclamation icon at the top right: top left "One charger with Dynamic Power Manager" (house icon, grey, not selected); top right "One or more fixed power charging stations" (pin icon, grey, not selected); bottom left "Multiple chargers in Power Sharing" (connected-nodes icon, grey, not selected); bottom right "Multiple chargers with an external master" (blue cloud icon with an upward arrow; blue outline and blue text, selected). Blue full-width button at the bottom: "Next".

Screenshot of an information screen in the DAZE app on a phone. Status bar: time 23:55 with a location arrow, signal bars, LTE, battery showing 5 with a red edge. Blue back arrow at the top left. Heading: "One charger with Dynamic Power Manager". Line drawing: a black outline of a charging-cable plug at the top, a black line down to a blue outlined EV charger (wallbox) shape with a small display and a dot; an orange line with an orange oval junction runs from the cable and from the charger to a black outlined house shape on the right. Text: "If only one charger is needed, the use of the Dynamic Power Manager is recommended." ("Dynamic Power Manager" in blue). Further text: "This function allows the charging power to be modulated so as not to exceed the meter limit. Once the grid parameters are set, the power delivered is automatically adjusted in order to always charge the car to the maximum available power." At the very bottom a black rounded bar (home indicator). No buttons are visible.

Screenshot of a phone app information screen "Multiple chargers with an external master" (DAZE app per the existing alt text). Phone status bar: time 23:55 with a location arrow, Dynamic Island with a green dot, signal bars, LTE, battery showing 5. Blue back arrow top left. Heading: "Multiple chargers with an external master". Illustration: a black outlined house icon at the top; a yellow line runs from the house down to the right-most of three blue charger icons; the three chargers stand in a row and are joined to each other by yellow lines (house connected to charger 3, charger 3 to charger 2, charger 2 to charger 1). Text: "To integrate your charger with external energy management systems select the External Master network." ("External Master" in blue). Second paragraph: "This feature allows you to control the charger and charging sessions via app, but the definition of charging power is defined by the external energy management system." No buttons are visible.

Screenshot of a phone app screen "Configure Wifi" (DAZE app per the existing alt text). Phone status bar: time 23:55 with a location arrow, Dynamic Island with a green dot, signal bars, LTE, battery showing 5. Blue back arrow top left. Heading: "Configure Wifi". Sub-heading: "Connection settings". Row with a Wi-Fi icon: "Enable WiFi" with a toggle switched on (green). Row: "Available networks" with a circular refresh icon; the list below is empty. Blue full-width buttons at the bottom: "Enter manually" and "Next".

Screenshot of a phone app screen "Configure Wifi" (DAZE app per the existing alt text). Phone status bar: time 23:56 with a location arrow, Dynamic Island with a green dot, signal bars, LTE, battery showing 5. Blue back arrow top left. Heading: "Configure Wifi". Sub-heading: "Connection settings". Row with a Wi-Fi icon: "Enable WiFi" with a toggle switched on (green). Row: "Available networks" with a circular refresh icon. Two networks are listed, each with a Wi-Fi icon, with the names partly covered by white boxes with black outlines: "My S" followed by a hidden part (black text); "LBS" followed by a hidden part (blue text, the entry in blue). Blue full-width buttons at the bottom: "Enter manually" and "Next".

Screenshot of a phone app screen to enter a Wi-Fi password (DAZE app per the existing alt text). Status bar: time 23:56 with a location arrow, signal bars, LTE, battery showing 5 with a red edge. Blue back arrow at the top left. Heading: "LBS" followed by a white box with a black outline that hides the rest of the network name. Subtitle: "Enter WiFi password". One outlined input field with the label "Password", empty, and an eye icon on the right to show the password. Large empty white space below. Blue full-width rounded button near the bottom: "Connect". Black home indicator bar at the very bottom.

Screenshot of a phone app screen "Charger configurations" (DAZE app per the existing alt text). Status bar: time 23:56 with a location arrow, signal bars, LTE, battery showing 5 with a red edge. Blue back arrow at the top left. Heading: "Charger configurations". Section label: "Access Management". Two radio options: "Free charger" (selected, filled black dot) and "Locked Charger" (not selected, empty circle). The rest of the screen is empty white space. Blue full-width rounded button near the bottom: "End". Black home indicator bar at the very bottom.

Screenshot of a phone app screen (DAZE app per the existing alt text) with a photo background of a grey and black EV charger. Status bar: time 23:56 with a location arrow, signal bars, LTE, battery showing 5 with a red edge. The charger photo has a black front panel with a blue light strip at the top, a small white seven-segment style display, a circular wave symbol and small car and plug icons; a thick black charging cable loops around the charger and ends in a black plug on the right. Over the photo is a light lavender rounded panel with a blue smiley icon and the blue text "Charging station association in progress". No buttons are visible. A black rounded home indicator bar at the very bottom.

Screenshot of a phone app screen listing chargers (DAZE app per the existing alt text). Phone status bar: time 23:56 with a location arrow, Dynamic Island with a green dot, signal bars, LTE, battery showing 5. Blue back arrow top left; a light blue pill button "Add charging station" at the top right. Title: "Reduxi". Tabs: "Chargers" (selected, blue with underline), "Sessions", "Settings", "Energy". Charger card: a photo of a light grey wall charger with a black display (blue light bar, "7,4 kW", icons, DAZE logo), an orange label "slave" at the top left and an orange heart icon at the top right. Below it: "Demo" and in blue "Dazebox Home S"; a green round icon with a moon and Z symbols, "Standby" and "-- kW". Second card: "Add charging station" with the text "Click on the button at the bottom to add a new charger" and a black round button with a white plus. Bottom navigation: "Favorites", "Networks" (selected, blue), "User", "Support".

Screenshot of a phone app charger screen (DAZE app per the existing alt text). Phone status bar: time 23:57 with a location arrow, Dynamic Island with a green dot, signal bars, LTE, battery showing 4. Blue back arrow top left, orange heart icon top right. Title: "Demo (Reduxi)" with a blue Bluetooth icon on the right. Tabs: "Dazebox Home S" (selected, blue with underline), "Sessions", "Configurations". Large photo of a light grey wall charger with a black display panel: blue light bar at the top, "7,4 kW", a round symbol, six small icons and the DAZE logo. Heading: "Charging mode", with a pill button "Standard". Six status tiles in two rows: "Vehicle" Unplugged (grey); "Access" Free (blue, open padlock icon); "Self-consum..." (text cut off) Disabled (grey, leaf icon); "Internet" Connected (blue, cloud icon); "Scheduling" Disabled (grey, clock icon); "Meter power" 17 kW (blue, house icon). Bottom navigation: "Favorites" (heart), "Networks" (house with bolt, selected, blue), "User", "Support".
